Woodworking Equipment For Sale

LIMTECH ORION-512 Flat Table CNC Router with Tool Changer & Boring:5' x 12' Capacity, great for "Nested Base Manufacturing" or just about any type of 3-Axis work.Axes travel range & feed speed: -- X-Axis 61" (1,550 mm), Y-axis with 145" (3,700 mm) and Z-axis 11.8" (300 mm). -- Working Table: 61" (1,550 mm) x 145" (3,700 mm); includes (3) pop-up stops to aid in panel positioning & a manual valve controlled 6-zone special high flow vacuum table system. -- X- & Y-Axis speeds are 2,165 IPM and Z-axis is 1,000 IPM for quick traverse positioning that reduces total CNC machining time between cutting cycles. -- DELTA Servo Drive powers the axes movement.Machine bed/base: -- The welded structurally engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- X-, Y- and Z-Axis travel: The moving gantry bridge travels on 1.2" (30 mm) thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool gantry & bridge movement by 1" (25 mm) rack & pinion; the vertical Z-axis travels on precision ball screw for smooth consistent and highly accurate movement.Routing/Machining: -- (1) 12 HP (8.8 kW) Air cooled "HSD" Router spindle with: HSK Tool holders, variable programming speeds from 1,000 to 24,000 RPM. -- Tools are loaded into the "HSD" spindle by (1) 8-position, side mounted on the fly tool changer. -- Tool heights can be set using the Tool Length Setting Gauge (included); machine uses ER-32 tool collets.Drilling/Boring: -- (1) Vertical 9-head spindle drills in L-shape configuration for 32 mm contstruction hole & line boring.CNC Control & Operator Interface: -- The "SYNTEC" INDUSTRY CONTROL System provides the operator an easy to use interface and the flexibility to customize to user specifications; Network-ready via Ethernet and USB flash drive. -- Features: Canned cycle, tool length diameter compensation, work coordinates-offsets, spindle feed rate overrides, program size up to flash drive size, DNC or drip feed operation and unlimited offset registrations. -- Compatible with virtually all CAD/CAM programming software on the market; you choose the software that best suits your needs.Complete with & Includes: -- Dust hood with 6" manifold connection; (4) HSK tool holders; Tool Length Setting Gauge; MPG hand held wheel remote. -- Vacuum Pump; 8 kW (11.5 HP) Vacuum Pump with ON/OFF pre-plumbed to control panel. -- Other Features: Machine Central lubrication, safety light beams and automatic homing operation. -- Machine weighs approx. 8,500 Lbs; 15 CFM air consumption at 90 PSI; machine power supply is wired for 220 Volts, 60 Cy, 3-Phase. Includes: Installation & Training by Factory Technician, and (1) Year Parts & Labor Warranty.

LIMTECH ORION-512D Flat Table CNC Router with Tool Changer & Boring:5' x 12' Capacity, great for "Nested Base Manufacturing" or just about any type of 3-Axis work. -- Axes travel range & feed speed: X-Axis 61" (1,550 mm), Y-axis with 145" (3,700 mm) and Z-axis 11.8" (300 mm). -- Working Table: 61" (1,550 mm) x 145" (3,700 mm); includes (3) pop-up stops to aid in panel positioning & a manual valve controlled 6-zone special high flow vacuum table system. -- X- & Y-Axis speeds are 2,165 IPM and Z-axis is 1,000 IPM for quick traverse positioning that reduces total CNC machining time between cutting cycles. -- DELTA Servo drive powers the axes movement. -- Machine bed/base:The welded structurally engineered machine base provides a solid foundation for superior cut quality; the entire frame is stress relieved and heat treated. -- X-, Y- and Z-Axis travel: The moving gantry bridge travels on 1.2" (30 mm) thick hardened & precision ground rectangle linear guide slider-ways giving extra smooth movement for high speed traverse and accurate cutting. -- Tool gantry & bridge movement by 1" (25 mm) rack & pinion; the vertical Z-axis travels on precision ball screw for smooth consistent and highly accurate movement. -- Routing/Machining:(1) 12 HP (8.8 kW) Air cooled "HSD" Router spindle with: ISO 30 Tool holders, variable programming speeds from 1,000 to 24,000 RPM. -- Tools are loaded into the "HSD" spindle by (1) 8-position, rack style tool station mounted on the end of the machine bed. -- Tool heights can be set using the Tool Length Setting Gauge machine uses ER-32 tool collets. -- Drilling/Boring:(1) 9-Vertical drills spindle head in L-shape configuration for 32 mm contstruction hole & line boring. -- CNC Control & Operator Interface: The "INTEK" INDUSTRY CONTROL System, gives the operator an easy to use interface and the flexibility to customize to user specifications; is Network-ready via Ethernet and with USB flash drive. -- Features:Canned cycle, Tool length-diameter compensation, Work Coordinates-Offsets, Spindle-Feed rate overrides, Program size up to flash drive size, DNC or drip feed operation and Unlimited offset registrations. -- Compatible with virtually all CAD/CAM programming software on the market; you choose the software that best suits your needs. -- Complete with & Includes:Dust hood with 6" manifold connection; assorted ISO 30 tool holders; Tool Length Setting Gauge; MPG hand held wheel remote. -- 15 HP Vacuum Pump; with ON/OFF pre-plumbed to control panel. -- Other Features:Machine Central lubrication, Safety light beams and Automatic homing operation. -- Machine weighs approx. 8,500 Lbs; 15 CFM air consumption at 90 PSI; machine power supply is wired for 220 Volts, 60 Cy, 3-Phase.

100 HP - 1800 RPM Belt driven. -- Jacketed water-cooled requiring 14 Gpm. -- All stainless wetting surfaces and replaceable stainless tools. -- 24" Inside diameter x 102" inside length. -- 14-1/2" x 18" inlet and 12" x 30" outlet. -- Capacity rating is 6,600 to 26,400 pounds per hour at 6 pound density.

Lobo 3-Head 43″ Wide Belt Sander (+ Flap/Brush Head)43" width cap, Drum, Drum, Combination HeadHead Configuration:1st Head: 9"; diameter grooved rubber-covered contact roll, with 20 HP – 1,760 RPM Motor.2nd Head: 9"; diameter grooved rubber-covered contact roll, with 15 HP – 1,760 RPM Motor.3rd Head: Combination Head with 6"; diameter grooved rubber-covered contact roll, smooth steel contact roll, with a 2″ air-inflated finishing platen, & 15 HP – 1,760 RPM Motor.Specifications -- All (3) heads have dial indicators for positioning PLUS a FOURTH dial indicator on the platen. The fourth head is a flap sander brush with a 3 HP motor -- Between heads one and two you will find hold-down shoes. Hold-down shoes control a workpiece as it passes through the sander, making it easier to run shorter parts through and prevent trailing edges and sniped or dubbed leading edges. -- Overall all capacity is 43″ wide X 5-5/8″ thick. -- Sanding Belt Dim. 43" X 75"Equipped with & Features: -- The feed mat, besides having 100% life, is 43″ wide and 7-1/2′ long. -- The feed motor is 3-1/2 HP and has variable speed from 5-45 FPM. -- The “FPC-515"; Touchpad Position Controller with LED Display for programmable thickness adjustment is in near flawless condition..

LOBO CT508 STRAIGHT KNIFE PLANER20" x 8" Capacity, 5 HP single phase motor, 4-knife - 5,000 RPM cutterhead, 7" minimum part length, 1/4" maximum stock removal, manual bed height adjustment. -- 20" X 26" Bed dimensions. -- Feed speeds 16 /20 FPM -- Cutter head speed 5,000 RPM -- Chain drive feed rollers -- Solid chip breaker -- Extension rollers for longer stock. -- Complete with magnetic control, start/stop feed clutch, and dust hood.

GB-CIS Single-end 575V / 3 Ph / 60 Hz 5” wide rubber pad conveyor Equipped with industrial motor for full power cutting and sanding capacity

Lobo 6-Head Moulder 9" Wide capacity

Year: 2006 Working Width: 25mm to 230mm (1" to 9") Working Thickness: 8mm to 120mm (0.31" to 4.72") Bottom Spindles (x2): 40mm diameter, 0-20mm transverse movement, 6000 RPM, 5.5kW (7.5 HP) Top Spindles (x2): 40mm diameter, 0-20mm transverse movement, 6000 RPM, 7.5kW (10 HP) Side Spindles (x2): 40mm diameter, 0-20mm transverse movement, 6000 RPM, 5.5kW (7.5 HP) Configuration: Bottom, Side, Side, Top, Top, Bottom Feed Motor: 4kW (5.5 HP) Elevation Motor: 0.75kW (1 HP)

LOCATELLI "OMK-300" Automatic Lathe with Sanding; From automatic feeding to finished product ejection - a complete "Turning & Sanding" System. -- 11-13/16" Max. between centers, 3-1/8" max. & 5/16" min. stock dia., 5.5 HP spindle motor with (3) spindle rotations of 3,020 - 4,580 & 6,400 RPM.6-Station Rotary Carousel/Drum with the following operations: -- Station 1: Pickup and centering of workpiece. -- Station 2: Turning with hydraulically operated roughing & finishing gouge. -- Station 3: Finish turning with hydraulically operated finishing gouge; rough & finish gouges advance via 1.5 HP hydraulic motor at a rate of 0.33 - 52 FPM. -- Station 4: Initial sanding with adjustable 0.5 HP vibrating brush. -- Station 5: Secondary sanding with adjustable 0.5 HP vibrating brush. -- Station 6: Ejection of finished workpiece. -- PLC Function for immediate fault detection and facilitates setup. Complies with CE high standards for operator safety. -- Features: Billet capacity has been increased to a special 5.9" x 5.9" (150 mm square). -- Complete with: Separate operator control panel. -- Includes: Inventory of spare parts and tooling. -- Machine kept under power but has not been used for production for several years.

Loewer Discmaster 6TD Brush Sander Vacuum Bed

Lower Denibbing Sander

LOEWER DENIBBING SANDER4-Head, 53" width cap., great Denibbing Sander -- The patented conbination of rollers and rotating / oscillating discs makes the Perfection BBDD sanding machiine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet foods, shutters, face frames, furniture and much nore. -- The LOWER DMBBDD sanding machine is sthe ideal soluton for all sanding applications including whitewood, stain and sealer coats(inciuding UV). The work piece first passes under two large counter rotating spiral hubs, then under eleven rotating discs that oscillate from left to right. This provides very uniform edge breading in whitewood sanding and eliminates most (if not all) hand sanding of the sealer coat. -- The patented combination of roller and rotating discs provieds very uniform sanding across the entire work piece, even into deep profiles without loosing detail. -- SPECIFICATIONS OF MACHINE --Thickness of work piece Min: 10mm (1/2")-- Max: 80mm (3") --Feed belt width Max:1350mm (53") --Feed belt motor 1.5 KW (3Hp) 3-15 M/min (10-50 Ft/min) --Top sanding roller 2.2KW (3Hp) 25-300 O/min (RPM) --Disc Rotation 2.2KW (3Hp) 25-300 O/min (RPM) --Disc Osciliatiojn ).37KW (0.5) 10-60 O/min (RPM) --Vacuum motor 7.5KW (10Hp) --Machine weight 1,800 kg -- Aproximate Machine dimensions based on similr machine W:2000mm (6'7")/ L:2780mm (9'2")/ H:6'11")

LOEWER DISC MASTER 3DBB Denibbing Sander with (2) Sanding Stations, 53" Width Capacity:53" Width cap. Denibbing Sander with a patented combination of rollers and rotating/oscillating discs make the LOEWER Discmaster 3DBB Sanding Machine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet goods, shutters, face frames, furniture and much more. -- Ideal solution for all sanding applications including whitewood, stain and sealer coats (including UV). -- Operation: The workpiece first passes under (16) rotating discs with abrasive brush loadings and then under (2) large counter-rotating spiral brush roller type hubs,Head Configuration: -- 1st Unit: (16) Rotating discs 250 mm (10") diameter each with (24) keyways 75 mm (3") long that oscillate from left to right; provides very uniform edge breading in whitewood sanding and eliminates most (if not all) hand sanding of the sealer coat. The discs are variable speed from 50 - 300 RPM by frequency inverter. Eccentric orbital disc movement (patent pending). Separate height adjustment of the disc station to run discs only or brush rollers only or everything together. Digital display to show the height of the discs. -- 2nd Unit: (2) - 400 mm 16" dia. rotating brushes sanding rollers powered by 2.2 kW gear motor with external coolers. -- Variable spindle speed 14 - 300 RPM adjusted by frequency inverter on each spindle and separately adjustable. The first drum rotates with the feed and the second rotates against the feed. Includes a panel blow-off station. -- The patented combination of rollers and rotating discs provides very uniform sanding across the entire workpiece, even into deep profiles without losing detail. Specifications: -- Disc oscillation by 0.37 kW (0.5 HP) motor, (0 - 60 Cycles/Min). -- Min. part thickness 4 mm (3/16") and max. 4"; -- Vacuum bed with 7.5 kW (10 HP) motor; Vacuum blower outlet on side of the machine has 200 mm outlet. -- Variable vacuum bed conveyor feed speed from 3 - 15 m/Min (8 - 50FPM). -- Pneumatic belt centering system. -- Fixed bed height for installation in a line. -- Separate variable speed adjustment for disc & roller. -- Antistatic brush strip device. -- Control panel Left Side-mounted. -- Emergency stop pull cords at both infeed and outfeed. -- Dust extraction outlets 3 x 80 mm (3.2") 4 x 140 mm (5.6") and 1 x 200 mm (8").Equipped with: -- PLC Touch-screen control: Simple & user-friendly "TOUCH SCREEN" PLC control with color monitor; PLC storage capacity for up to (25) individual sanding programs; -- the PLC control interface also allows for easy machine connection to a flat-line, tow-line or hanging-ling finishing system.

dowel machine made by Loser Machine type: AA 220 Machine # 1116 Bi 80 Voltage: 440 Hertz 60 Removed from service November 2020. for dowel diameter approx. 6-13 mm smallest cutting length 15 mm The dowel length is adjustable between 20 and 150 mm and is determined by means of an adjustment scale. The chamfer thickness can be set as required.

Reconditioned MAC 144MCF153 Reverse Air Bag House, 2,219 SQ/FT Cloth Media, 18,000 CFM Capacity @ 8:1 Air/Cloth Ratio, 12” Rotary Valve, Structural Support, VERY GOOD CONDITION, $38,000

MACMAZZA TS 90 FRONT LOAD, AUTO. PANEL SAW: -- Specifications: -- 169" Cutting length; 2.83 effective cutting height, 12 HP main saw motor. -- Features: -- Variable saw carriage travel speed 3 - 328 FPM, constant return of 328 FPM; electronically controlled overhead program fence, rack & pinion driven on both sides, forward & return speed 2 - 164 FPM, equipped with (6) clamps. -- PC-Based LENOVO 90GA computer control with CELERON Quad-Core J3455 Processor & 19" color monitor, 4 GB RAM, 1,000 GB Hard drive, (6) USB Ports. -- Complete with: -- Rear table constructed of aluminum profiles with plastic rollers, (3) front air floatation tables; side pressure device for crosscutting on pressure beam.Photos not of actual machine.

1997 NPN MACO Tie Machine, s/n 1997001, 100hp electric motor on side planers, includes electric control box, 4-1/2" capacity, power outfeed.

MAGGI SYSTEM 21 PRESTIGE Construction & Line BorerAdjustable 21-spindle boring head on 32 mm centers with position indicator.Specifications: -- Stops in 0° and 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with magnifying glass viewer. -- 2 HP - 2,800 RPM Motor. -- 34" x 15" Table with mechanical digital side fences for mirror-image. -- 120" Line Boring fence with (2) repeat stops. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks.OPTIONAL: -- 230V Single Phase add $600.00 --29900100 Stop Reference Pin for Line Boring $195.00 -- 26000069 Set of Reference Fences for 45 and 90 degrees $195.00 -- 36000061 Additional Quick Change Bit Adaptor $27.50 ea -- 29971019 Additional Holddown Cylinder Assembly $395.00 ea -- Hinge Boring Head (Specify Blum, Grass, Salice, or Hettich) $695.00 -- TDBSE5705LH or RH 5mm x 57mm LH OR RH Brad Point $9.85 ea -- TDBSE5708LH or RH 8mm x 57mm LH OR RH Brad Point $11.95 ea -- TDBSEHB5735LH or RH 35mm x 57mm LH OR RH Hinge Point $26.80 ea -- FREIGHT TO ANYWHERE IN THE CONTINENTAL USA $ 300.00

MAGGI SYSTEM 23 Construction Hole Boring Machine Adjustable 23-spindle boring head on 32 mm centersSpecifications: -- Stops in 0° & 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with a mechanical digital readout. -- 2 HP - 2,800 RPM Motor. -- 38" x 16" Table with mechanical digital side fences for mirror-image. -- 120" Line Boring fence with (4) repeat stops & spring loaded repeat pin. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks. -- Dust Outlet: 3".Net weight: 630 Lbs; Dimensions: 51.7" x 37.8" x 50" Tall; Crated Dimensions: 44" x 38" x 42" Tall; Crated Weight: 664 lbs.Available in single phase ... Add $ 600.00

MAGGI SYSTEM 29 CONSTRUCTION/LINE BORERAdjustable 29-spindle boring head on 32 mm centers with position indicator. -- Stops in 0° & 90° with pneumatic positioning in vertical & horizontal. -- 0" - 2-1/2" Adjustable drilling depth with patented setting device. -- (2) Patented material clamps with auto-setting & safety feature. -- Head height fine adjustment with mechanical digital readout. -- 2 HP - 2,800 RPM Motor. -- 45" x 16" Table with mechanical digital side fences for mirror-image. -- 120" Line boring fence with (4) repeat stops & spring loaded repeat pin. -- Foot actuated pneumatic clamps & drill cycle. -- Magnetic starter, overload protection and (1) set of "quick change" chucks. -- Other Accessories also Available!
