QUINDAO YICH - YICH-BC600, ...Automatic Feed Through Moulding Sprayer w/Drying Tunnel & 18" width cap. Machine setup: (2) C.A. TECHNOLOGIES AUTOCAT HVLP" low pressure Spray Guns and (1) GRACO "D54311" twin-diaphragm pump. This machine has only sprayed water for testing its operation and never used finishing spray materials.Conveyor belt: PU Abrasion resistant and chemically resistant material; conveyor driven by an electric motor and gear reduction box; overall construction: Cold roll steel plates, bent & joined for stable construction.Sprayer with: (3) Chambers are closely spaced and removable for cleaning; Guns are adjustable in height & angles to set the best angle for coverage; parts are guided into the machine by left/right roller guides. Specifications: -- Max. workpiece width: 600 mm (24") -- Min./max. part thickness: 10 - 120 mm (1/2" - 4-3/4") -- Min. part length: 600 mm (24") -- Feed speed: Adjustable, 15 - 100 FPM -- Number of spray guns: (6) -- Overall Dimensions - 3500 mm x 2100 mm x 2560 mm -- Weight 1000 kG (2,200 Lbs .. need to confirm)Electric powered IR oven with circulating airOven is a variable speed and variable temperature using a roller type conveyor. Current owner has used the oven at 200FOven Specifications: Min/Max part width ½" – 15 ½" Min/Max part thickness ½" – 5" Variable feed speed up to 50 FPM (14 MPM) Feed motor power 1.5 kW Fan power 1.1 kW Heating Power 10.8 kW Overall size 32’ × 38" x 67" H

RADER - Trailer Dumper with 30 ft. Tipping DeckComes with the following components and features: -- This unit was installed at the current location in approx. 1971 and is reportedly in great working order and condition. -- Previously used for Dumping Wood Chip Trailers. -- Professional rigging and loading is available. Decks are often extended for longer (53 ft.) trailers.

RAIMANN Model ASA 1650 II, Veneer Patcher.Specifications: -- 5HP gearmotor, drive conversion wit new clutch and motor. Strip type mechanical plug-feeder mechanism - cap.. of up to (40) Plugs/Min.; -- Thickness of veneer patchable 1/32" - 3/16" (0.8 mm - 4.76 mm). Profile P-34 dies in good condition. -- Table dimensions approx. 39" x 47" -- Throat distance from tool to back column 65" -- Table height 35" -- Tool sequence: Veneer patch is cut by the table die and scrap is ejected into discharge chutes, veneer patch blank is then positioned against the underside of the table die, plug punch cuts replacement veneer patch from underside and patch is inserted into the proper position. -- Reconditioned by experts. -- Overall size: 10' 8" (3,250 mm) Length x 67" (1,700 mm) height; approx. weight 12,000 Lbs (5,450 kG). --Option: Veneer Strip Feeder. Feeds standard strip widths continuously. Venturi vacuum cup strip feed mechanism. All pneumatic operation. 120 Volt/60 Hz controls.please inquire for price extra. --Actual model is RAIMANN Model ASA II 1650.

RAIMANN - KM-310, ...Gang (Multi-Blade) Rip Saw12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Features: -- "Quickfix Hydro-Quick" Arbor: Multiple Saw blades are mounted on the arbor, they slide up-and-down the arbor into position and lock into place by tightening the end of the arbor; no tools & no spacers required. -- Frequency controlled feed speed of 13 - 110 FPM, 2.2 HP feed drive, chain spikes every 3rd chain link, automatic chain lubrication.Specifications: -- 300 mm (11.8") Max. saw blade dia. with 80 mm (3.15") bore, 65 mm (2.55") dia. arbor. -- Provides 3" max. depth of cut with pressure shoe, 3-1/2" depth of cut without. -- Manual thickness adjustment of upper holddown rolls with indicator scale. -- 6" Throat depth to the right of blade; 7/8" min. strip width, 17-3/4" min. stock length.Equipped with: -- (4) Sets of top & bottom antikickback fingers. -- Extended infeed with additional bed roll, and adjustable infeed fence. -- Motor load meters and automatic STAR DELTA starting. -- Automatic over thickness shutoff on infeed and 7-1/4" dia. dust hood. -- (4) Laser lights.Also included: -- (6) Used blades.

RAIMANN KM 310 1M - Movable Blade Gang Rip Saw; 12-1/4" Max. width cap.; 13-1/2" chain width; with 25" width clearance,Specifications: -- 50 HP - 4,200 RPM V-belt drive arbor with (1) movable and (2) fixed blade; shifting blades positioned from operator controls. -- As the computer or operator moves blade, laser light follows; fixed saw blade with "Quick Fix" hydro-arbor is mounted on an individual collar that slides up-and-down the arbor into position, then locks into place by tightening end of arbor; no tools & no spacers required.Equipped with: -- Blade capacity 11" to 14.1" (280 -380 mm) Dia. saw blades, 65 mm (2-1/2" dia.) arbor, 4-1/4" max. depth of cut, 17-3/4" centers between upper holddown rollers (phenolic pressure holddown shoe plate included); 3/4" min. strip width, 19-1/2" min. stock length. -- Variable feed speed from 13 - 115 FPM, feed drive 2.2 HP motor, provision for chain spikes every 3rd chain link, automatic chain lubrication. -- (2) Sets of top & bottom anti-kickback fingers, extended infeed with additional bed roll, and adjustable infeed fence.Complete with: -- Automatic over-thickness shutoff on infeed. -- (4) Laser Lights. -- Automatic STAR-DELTA starting. -- "ProfiCut 1" PLC Controls. -- 8" Dia. dust hood. -- Includes with approx. (9) blades.Dimensions: 85" x 56" x 73" H. Weight: 3,750 Lbs.Note: Stated condition reflects that the chain is worn and per owner "?Chain should be replaced."

RAIMANN KR 310 2M Multiple Rip Saw System ( 2 Moving Blades )12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with:& Features -- Quick Fix arbor with: (2) Movable blade and (3) fixed blades; -- Moveable Operator Pedestal w/ LED Screen and Push-Button Controls. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler for guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. Cutting Specifications -- Blade Diameter: 9.8" - 15" -- Cutting depth with 12" Dia. saw blades, 2-1/2" with pressure shoe; 4" without pressure shoe. -- Variable feed speed, 16 - 158 FPM, feed drive 2 HP motor.Additional Features -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over thickness shutoff on infeed. ÷ Automatic starting and swing arbor mount for control panel.

RAIMANN (WEINIG) Variorip 310 M with Infeed and (2) Moving Blades SystemClean, very hard-to-find 2014 ( Infeed 2022 ) Weinig Raimann Variorip 310 M Optimizing Rip Saw with (2) moving blades and Infeed SystemSpecifications -- Working dims: Length 24″ to 184″; width to 12.2″ (310 mm) and thickness .59″ to 3.94″ (184″ is fence length) -- Cutting dims: Width min. 5/8″ (1st movable blade); min. 1-5/8″ to 10-1/4″ (2nd movable blade) and fixed pocket 1″ -- Production in auto mode 7 x 10′ boards per minute. -- Saw: 50 HP motor with arbor dimension of 2.6″; RPM of 4200. -- Quick fix arbor (hand turn nut) for position blades. -- Saw blade dia. 12″ to 14″ (300 - 350 mm). -- Blade positions by ball screw adjustment. -- Chain: Width 12-3/4″ steel chain with every 3rd link with spikes --. Automatic oiler for chain lubrication. -- The chain has auto shut-off when the oil level is low. Roto chain brush for continuous chain cleaning of debris. (4) set of antikickback fingers. -- Feed: Variable 26-157 FPM (8-48 m/min) with 3 HP motor.Equipped with and Features: -- Controller: Raimann TimberMAX, with 15″ color screen with storage for 100 cut lists, -- Production recording and yield. -- Also includes: (4) Lasers with mounts, spare parts, & manuals.Foot Print & Weight: Infeed is 3,306 Lbs and roughly 8' x 16'Saw is 4,603 Lbs and roughly 6' X 6'The saw slightly offsets the infeed. So the footprint together is a little larger.....probably closer to 9' x 23'NOTE Saw is 2014 INFEED is 202SOME Spec's need to be verified

RAIMANN KR 310 2M Multiple Blade Rip Saw System with Valu-Rip Infeed12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Specifications -- Quick Fix arbor with: (2) Movable blades and (3) fixed blades; (5) Laser Lights. -- Enlarged movable saw housing with 25" pass-through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler for guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods.Cutting Specifications: -- The cutting depth with 12" Dia. saw blades is 2-1/2" with a pressure shoe and 4" without a pressure shoe. -- The variable feed speed is 16 - 158 FPM, and the feed drive is a 2 HP motor.Equipped with & Features: -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over-thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.Also included: -- Valu-Rip infeed system 16' long -- (4) Movable Laser light

RAIMANN KM-US BV Gang Rip Saw with one (1) Moving BladeSpecifications: -- (1) Shifting blade with foot pedal control; -- Fixed blades mounted to individual collars that slide up-and-down the arbor into position, then lock into place by tightening the "Quick fix" nut on the arbor, no tools & no spacers required. -- 12" Dia. saw blades, 65 mm (2-1/2" dia.). -- Arbor, 3-1/2" max. depth of cut. -- 20" centers between upper holddown rollers (wood holddown shoe plate not included). -- 6" Throat depth to the right of the blade. -- 3/4" Min. strip width, 21" min. stock length.Equipped with & Features: -- Variable feed speed 16 - 110 FPM, -- Feed drive 1.2 HP motor; -- Chain spikes every 3rd chain link, -- Automatic chain lubrication, -- (2) Sets of top & bottom anti-kickback fingers, -- Extended infeed with additional bed roll, adjustable infeed fence. -- Complete with: Automatic over-thickness shutoff on infeed, -- Automatic starting, -- 8" Dia. dust hood. -- Includes (4) Lasers and Tooling as pictured.

RAIMANN KR 310 2M Multiple Rip Saw System ( 2 Moving Blades )12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with:& Features -- Quick Fix arbor with: (2) Movable blade and (3) fixed blades; (5) Laser Lights. -- Enlarged movable saw housing with 25" pass through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler fo guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. Raimtech E5 with TimberMax Software optimizing software; makes it possible to get the most out of incoming lumber. -- The software optimizes rips for width or grade. -- TimberMax calculates the most profitable ripping solution for each board at which time shifting saw blades are positioned automatically. -- Infeed includes a infeed belt conveyor with pressure roller. -- Infeed is mounted on slide that automatically adjusts the board in the best position before entering the saw. -- Conveyor is 24" wide X 120" long. ( This option has to be verified )Cutting Specifications -- Cutting depth with 12" Dia. saw blades, 2-1/2" with pressure shoe; 4" without pressure shoe. -- Variable feed speed, 16 - 158 FPM, feed drive 2 HP motor.Additional Features -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.

RAIMANN KR 310 2M Multiple Blade Rip Saw System with Valu-Rip Infeed12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with: -- Quick Fix arbor with: (2) Movable blades and (3) fixed blades; (5) Laser Lights. -- Enlarged movable saw housing with 25" pass-through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler for guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. -- Raimtech E5 with TimberMax Software optimizing software; making it possible to get the most out of incoming lumber. The software optimizes rips for width or grade. TimberMax calculates the most profitable ripping solution for each board at which time shifting saw blades are positioned automatically. Infeed includes an infeed-belt conveyor with a pressure roller. Infeed is mounted on a slide that automatically adjusts the board in the best position before entering the saw. The conveyor is 24" wide X 120" long.Cutting Specifications: -- The cutting depth with 12" Dia. saw blades is 2-1/2" with a pressure shoe and 4" without a pressure shoe. -- The variable feed speed is 16 - 158 FPM, and the feed drive is a 2 HP motor.Features: -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over-thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.Also included: -- Valu-Rip infeed system 16' long -- (4) Movable Laser light Note: The machine, chain feed, and arbor, have recently been refurbished.

RAIMANN KR 310 2M Multiple Rip Saw System ( 2 Moving Blades )12-1/4" Max. width cap., 13-1/2" chain width, 50 HP - 4,200 RPM V-belt driven arbor.Equipped with & Features: -- Quick Fix arbor with: (2) Movable blade and (3) fixed blades; (4) Laser Lights. -- Enlarged movable saw housing with 25" pass through. Ball threaded adjustment of spindle. Saw blades mounted to individual collars. -- Chain with spikes every 3rd link, with automatic oiler with indicator light. -- Driven fluted lower roller with smooth upper roller for smooth feeding. Auto oiler for guide lubrication. -- (4) Sets of anti-kickback fingers and 12" dia. dust hoods. Cutting Specifications -- Cutting depth with 12" Dia. saw blades, 2-1/2" with pressure shoe; 4" without pressure shoe. -- Variable feed speed, 16 - 158 FPM, feed drive 2 HP motor.Additional Features -- Sound enclosure with vertical pneumatic lifting -- Adjustable infeed fence. -- Automatic over thickness shutoff on infeed. -- Automatic starting and swing arbor mount for control panel.Note: Transformer for 600 volts included if necessary

RAMCO DW-25A SINGLE HEAD WIDE BELT SANDERSingle Head 36" Wide Belt Sander with combination head. -- 4" Dia. rubberized contact drum and 2-1/2" finishing platen. -- 10 HP Sanding belt motor and 1 HP feed motor. -- 37" x 60" Belt capacity. -- Motorized thickness setting of 0" - 5-1/2" capacity. -- (2) Jackscrews to move the table-up-and down. -- Variable conveyor speeds of 15 - 45 FPM. -- Infeed & outfeed spring loaded holddown rollers. -- Load meter and safety shutoff. -- Options: 12" Infeed extension table and 25" x 75" belt capacity.

RAMCO DW-37W SINGLE HEAD WIDE BELT SANDERSingle Head 36" Wide Belt Sander with combination head. -- 4" Dia. rubberized contact drum and finish platen. -- 15 HP Sanding belt motor and 2 HP feed motor. -- 37" x 60" Belt capacity. -- Motorized thickness setting of 0" - 6" capacity. -- (4) Jackscrews to move the table-up-and down. -- Variable conveyor speeds of 15 - 45 FPM. -- Infeed & outfeed spring loaded holddown rolls. -- Load meter and safety shutoff. -- Options: Infeed extension table and 37" x 75" belt capacity.

Single head, 36" width cap. - 7" Dia. rubber covered contact snadeing roll followed by an adjustable 2-1/2" Wide finishing platen, 20 HP motor. -- 37" x 75" Abrasive belts, electronic abrasive belt tracking. -- Equipped with: Infeed & outfeed spring loaded holddown rolls, 0" - 6" max. motorized part thickness opening and Programmable thickness adjustment; 15 - 45 FPM variable feed speed driven by a 2 HP. motor. -- Complete with: Air operated disc brakes, motor load meters.

SCM PRATIX S-15-B FLAT TABLE MACHINE (W/ATC/BORING) -- Specifications: Single 5' x 12' traveling "Bridge Gantry" and stationary aluminum dual vacuum table with: "MATRIX" Square grid pattern for fixturing parts.Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested base machining".Part location pop-up pins mounted on the table perimeter. -- Working Field"X" Axis is 145.11" (3,686 mm); "Y" axis is 61.2" (1,555 mm); "Z" axis stroke is 9.8" (250 mm); max. material thickness: 5.9" (150 mm). -- Positioning Speed"X" & "Y" Axis 229 FPM (70 MPM); "Z" axis at 82 FPM (26 MPM); closed loop AC Servo drive system.High precision "Rack & Pinion" system in "X" & "Y" axis & ground ball screws "Z" axis; all axes ride on extra-large precision profile linear guideways. -- Boring Unit - 3 HP (2.2 kW) - 6,000 RPM Motor; (7) vertical spindles on 32 mm centers; (5) spindles in "X" axis & (2) spindles in "Y" axis. -- Machining - (1) 9 HP (6.7 kW) Air-cooled electrospindle with: HSK F63 Adaptor; variable spindle speeds from 1,500 - 24,000 RPM.(1) 10-Position ATC tool rack mounted to the machine base. -- Operator & Machine ControlPC Front-End with: "XILOG Plus" + Windows "XP Pro" Operating System; 17" high resolution LCD; ergonomic keypad; CD ROM & 1.44 MB disk drives.USB Ports; serial ports RS-232 & RS-242 & Ethernet adaptor; programs can be transferred via disk or downloading by wire is possible.All computer components are mounted on a mobile stand.XILOG Plus - Offers incredible list of functions from: (a) Auto diagnostic to (z) zooming; controlled acceleration & deceleration; encoder feedback; dynamic tool correction via PLC due to active tool wear using space-and-time criteria. -- Additionally Equipped with:Onboard mini CAD with built-in programming for: Writing circles, ellipses & angles with only a few keystrokes; onboard cycle optimization; onboard calculator; mirror imaging, and repeat imaging. -- Complete with:(2) 150 cbm/Hr Vacuum Pumps; safety enclosure around the spindle carriage; (1) Universal Remote Pendant; 7" color display allows for the effective management of all machine functions from manual Jog Mode to loading & execution of a program.The pendant is fitted with a USB port to allow quick load & setup of new programs; safety "bump stop" bumpers; emergency stop rope, manuals. -- Options Include:Rake System for removing finished product and sweeping up dust residue. -- Actual Model: SCMI PRATIX S 15 B

SCM TOP 35 BORING MACHINE(35) Spindles on 32 mm centers, pivoting boring head, drills vertically from the top and horizontally from the rear,Specifications: -- 0° - 90° Motorized tilting of the head, can be locked at any angle between; max. panel width 1.280 mm. -- (2) 6 HP - 2,800 RPM Motor; quick boring depth setting with (6) depth stops on revolving turret, viscous damper for smooth drilling & through boring. -- Designed with: Lead screw w/veneer scale for head displacement setup.Complete with: -- Back fence w/flip stops, plus fence extension with (4) mechanical reference stops, (4) pneumatic hold-downs; 33" worktable height.

SCM TECH Z 30 CNC MACHINING CENTER (W/ATC/BORING): -- Specifications:Working Field "X" axis 120" (3,050 mm); "Y" axis 52.7" (1,340 mm) for routing & 44" (1,118 mm) for boring; "Z" axis stroke 7.8" (200 mm); max. material thickness 3.9" (100 mm). -- Positioning Speed:"X" & "Y" Axes are 197 FPM (60 MPM); "Z" axis is 72 FPM (22 MPM).Axes positioning by: AC Brushless motors and YASKAWA drives; high precision ball screw drive system in "X", "Y". "Z" Axes;All axes ride on prismatic guideways & sliding blocks. -- Worktable:(6) "TV" Tubeless mobile support rails, (2) vacuum pods per rail; (4) pneumatic lifter rails for heavy panels.(6) Pneumatic pop-up backstops, (6) pneumatic pop-up front stops; (2) pneumatic pop-up side stops.LED Display positioning assistance for the support rails & vacuum pods; (2) independent working fields. -- Boring Head:3 HP (2.2 kW) motor - 4,000 RPM; (15) independent vertical spindles: (8) Spindles in "X" & (7) spindles in "Y".(6) Horizontal spindles (2 + 2) in "X" & (1 + 1) in "Y-axis".(1) X-axis grooving saw with 100 mm dia. blade - 6,000 RPM. -- Machining:(1) 10 HP (7.5 kW) Electro-spindle router with: HSK F63 Adaptor; variable speed from 1,000 - 24,000 RPM, max. torque achieved at 12,000 RPM.Static inverter for stepless speed & rapid shutdown rotation.(1) 6-Position ATC tool plate mounted on the on the machine for "on the fly" ATC; max. tool weight is 8 kG (17.6 Lbs). -- Operator & Machine Control:PC Front-End with: SCM "UNIVERSAL K2" + "Xilog Plus" + Windows "XP" Pro Operating System; 15" CRT color display, CELERON 2 GHz processor, enclosed in air-conditioned cabinet. -- Complete with:(1) 100 m³/Hr Vacuum Pump; automatic lubrication system; "BUMP STOP" safety system. -- Actual Model is SCM TECH Z30 R6

SCMI ROUTECH RECORD 125 N FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 10' Single Table machine: stationary extruded aluminum table is machined with a square grid pattern for fixturing parts,Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested based machining". -- Working field:"X" axis 125" (3,175 mm), “Y"; axis 60"; (1,524 mm) , "Z" axis stroke is 12" (305 mm). -- Positioning speed:"X" axis 260 FPM (80 MPM), "Y" axis 180 FPM (55 MPM), "Z" axis 82 FPM (25 MPM);Closed loop AC Servo drive system driving precision ground ball screws, all axes ride on extra large precision profile linear guideways. -- Boring Unit:(12) Independent vertical spindles, (7) in "X" axis & (5) in "Y" axis;(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis. -- Machining:(1) 15 HP (11.2 kW) Liquid Cooled "Power 2000" Electro spindle w/lifetime lubrication & HSK F63 adaptor, spindle speeds from 6,000 - 18,000 RPM;(1) 12-position ATC tool plate mounted on the head for "on the fly" ATC. -- Operator & Machine Control:PC Front end with "ESA-GV Kavara6" + WINDOWS operating system; "NUM 1000" PLC featuring (3) axes simultaneous control,15" high resolution CRT; 1.2 GB Hard drive, ergonomic industrial keyboard & mouse; 1.44MB floppy disk drive; serial ports for RS-232; all housed in a separate dust free cabinet -- Complete with:(1) 250 m³/Hr + (1) 100 m³/Hr vacuum pump; Pressure safety mats. -- Actual Model is SCMI Routech Record 125 N.

SCMI ROUTECH RECORD 125 N FLAT TABLE MACHINE (W/ATC/BORING): -- Specifications:5' x 10' Single Table machine: stationary extruded aluminum table is machined with a square grid pattern for fixturing parts,Grid pattern allows use of vacuum pods or closed cell rope gasketing material and use of spoil boards for "nested based machining". -- Working field:"X" axis 125" (3,175 mm), “Y"; axis 60"; (1,524 mm) , "Z" axis stroke is 12" (305 mm). -- Positioning speed:"X" axis 260 FPM (80 MPM), "Y" axis 180 FPM (55 MPM), "Z" axis 82 FPM (25 MPM);Closed loop AC Servo drive system driving precision ground ball screws, all axes ride on extra large precision profile linear guideways. -- Boring Unit:(12) Independent vertical spindles, (7) in "X" axis & (5) in "Y" axis;(6) Horizontal spindles with (2+2) in "X" axis & (1+1) in "Y" axis. -- Machining:(1) 15 HP (11.2 kW) Liquid Cooled "Power 2000" Electro spindle w/lifetime lubrication & HSK F63 adaptor, spindle speeds from 6,000 - 18,000 RPM;(1) 12-position ATC tool plate mounted on the head for "on the fly" ATC. -- Operator & Machine Control:PC Front end with "ESA-GV Kavara6" + WINDOWS operating system; "NUM 1000" PLC featuring (3) axes simultaneous control,15" high resolution CRT; 1.2 GB Hard drive, ergonomic industrial keyboard & mouse; 1.44MB floppy disk drive; serial ports for RS-232; all housed in a separate dust free cabinet -- Complete with:(1) 250 m³/Hr + (1) 100 m³/Hr vacuum pump; Pressure safety mats. -- Actual Model is SCMI Routech Record 125 N.
