STAR V MACHINERY - SCG-1600: Automatic Cross Groover -- Specifications(1) Spindle with: 12 HP - 3,600 RPM Motor; 60" max. crosscut cap.; material thickness: 0.25" - 1.125".(1) Internal 60" stroke Tape Applicator Station. -- 96" Stroke Servo motor driven Rear Pusher Fence (full 60" rear table width); 96" long x 20" front table with: (5) Digital manual stops. -- Rear Fence Movement, Cutter forward Speed Cut/Tape Stroke and All Controls for Start/Stop, On/Off, Axis position Displays on 10" Touch Screen Panel HMI. -- Grooving head up & down movement via pneumatic cylinder with: Linear rail & linear bearings; depth fine adjustment with special threaded adjustable unit. -- Carriage cross travel powered by: 3 HP Hydraulic motor (4 GPM); driven ball screw with: Linear rail & linear bearings; feed rate: 0 - 40 FPM; Heavy-Duty welded frame construction. -- Complete with:Safety guards & cutter guards; pneumatic support fence; (1) Heavy-Duty infeed/outfeed roller tables. Available options at additional cost below:Accessories, Tooling & Tape: Choose and add to machine base price. Cove Corner Plug Jig: ...$ 575 ea. Brazed carbide 90° cutter for up to 1/2" solid surface: ...$ 745. Please specify the material. Brazed carbide cove backsplash cutter for 1/2" solid surface: ...$1,265 ea. Please specify 3/8" or 1/2" radius. Brazed carbide 90° cutter for up to 3/4" wood materials: ...$ 940.00. 90° Insert cutter for up to 1/2" thick material (body only): ...$1,265.00. Requires below inserts.......90° V-Insert for up to 1/2" thick material: ...$32 ea. min. of (12) inserts required: ...$ 384.......Carbide insert cove backsplash cutter head for 1/2" material (body only): ...$1,590 ea. Please specify 3/8 or 1/2 Radius.Requires Below Inserts:......3/8" Cove radius insert for 1/2" thick material: $42 ea. Min. of (12) inserts required. ...$ 504. ......3/8" Double 45° insert for 1/2" thick material: $42 ea. Min. of (12) Inserts required. ...$ 504.......PCD Diamond 90° cutter for up to 1/2" thick material $3,485 ea.......PCD Diamond cove cutter with 1/2" radius for 1/2" thick material: $ 5,645.00 ea. Roll of VAC2MG: 2" (50 mm) wide; 1,025 y (937 m) long roll V-Groove tape: $ 245. ea.& Minimum of (3) rolls per order = $735. -- Actual Model: STAR V MACHINERY - SCG-1600: Automatic Cross Groover

STAR V MACHINERY SLG-2000 36 LINEAR V-GROOVER: -- SpecificationsWorking table dimensions: 120" Long x 36" wide; working width: 6" - infinite" (152 mm - infinite); working length: 20" - infinite (508 mm - infinite); working thickness: 0.25" - 1.15" (6 - 29 mm).Max. throat clearance for linear & crosscuts: 14-1/2"/24-1/2" (355/622 mm). -- Equipped with: (2) Independent 10 HP - 3,600 RPM saw motors with: "Servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple fold profiles, or using it for hogging and finish cut; 9-1/4" (235 mm) max. cutterhead dia.(1) Saw motor mounted on the front & (1) Saw motor mounted on the back of the 8" x 12" x 1/2" heat treated steel Heavy-Duty overhead support beam.Side-to-side head travels via linear rails & bearings; manual head height adjustment via linear rails & bearings. -- Feeding System(1) 3 HP Variable speed drive belt system with: "Servo" height adjustment; feed rate: 0 - 45 FPM (12 MPM); belt feeder moves workpiece on a precision "aluminum" roller table. -- Tape Applicator (2) Automatic Tape Applicators with: "Servo" adjustment according to the Saw motor position in "Y" axis. -- Operator Interface10" HDMI Touchscreen display for: Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:Safety guards and cutter guards; Anti-Kickback Device; Emergency Shutoff line.Dust Collection requirements: 4,200 CFM; Collector outlets on cutter guards: 5" in dia. -- Actual model #: STAR V MACHINERY SLG-2000

STAR V MACHINERY SLG-2000 48" LINEAR V-GROOVER: -- SpecificationsWorking table dimensions: 120" Long x 48" wide; working width: 6" - infinite" (152 mm - infinite); working length: 20" - infinite (508 mm - infinite); working thickness: 0.25" - 1.15" (6 - 29 mm).Max. throat clearance for linear & crosscuts: 14-1/2"/24-1/2" (355/622 mm). -- Equipped with: (2) Independent 10 HP - 3,600 RPM saw motors with: "Servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple fold profiles, or using it for hogging and finish cut; 9-1/4" (235 mm) max. cutterhead dia.(1) Saw motor mounted on the front & (1) Saw motor mounted on the back of the 8" x 12" x 1/2" heat treated steel Heavy-Duty overhead support beam.Side-to-side head travels via linear rails & bearings; manual head height adjustment via linear rails & bearings. -- Feeding System(1) 3 HP Variable speed drive belt system with: "Servo" height adjustment; feed rate: 0 - 45 FPM (12 MPM); belt feeder moves workpiece on a precision "aluminum" roller table. -- Tape Applicator (2) Automatic Tape Applicators with: "Servo" adjustment according to the Saw motor position in "Y" axis. -- Operator Interface10" HDMI Touchscreen display for: Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:Safety guards and cutter guards; Anti-Kickback Device; Emergency Shutoff line.Dust Collection requirements: 4,200 CFM; Collector outlets on cutter guards: 5" in dia. -- Actual model #: STAR V MACHINERY SLG-2000

STAR V MACHINERY SLW-4818 SLAT WALL GROOVING MACHINE: -- Specifications48" wide panel capacity, feed through style overhead milling Slatwall machine. The machine will produce 4' x 8' panels in portrait orientation or any orientation as long as the panel size does not exceed 4' x 4'.The panels are placed with side to be grooved, facing up, then pushed in between the fixed fence and a movable fence, until the panel is grabbed by the first rubberized feed roller, the panel is then transported between a number of pinch rollers and processed through 3 rows of high-speed spindle motors.As the T Slot cutting is processed each bank (6 in total) of 3 high speed spindle motors cut a T shaped groove appropriate to the size of tool installed in each spindle, blow the groove clean by use of high-speed air knives, and remove dust through a number of dust ports. Then pinch rollers push the sheet out of the machine roller bed.Panels as narrow as 6" wide can be fed through the machine although workpieces less than 3/8" thick must be 48" wide. Workpieces as short as 24" can also be fed through the machine safely.Minimum recommended workpiece width, 6": Maximum workpiece width, 48": Minimum recommended workpiece length, 24": Maximum workpiece length, UNLIMITED: Maximum workpiece height, 1.5". -- Features:5HP 1750RPM, 460V Feeder Drive Motor through 50:1 Gear Box. 5HP VFD Inverter to drive and control feed speed through machine, 0-50 linear feet per minute. Heavy Duty Welded Tubular Steel Frame Construction. Stainless Steel Roller Bed with Rollers 6" on Center. 10x Linatex Rubber coated Feed Pinch Rollers Driven by 5Hp Feed Motor and Drive. Fixed Guide Fence& Movable fence to aid feeding of sheets into machine. Safety Fence around both sides along the length of the machine, with 1 gate in each side, each with safety interlock. Safety photo eye in infeed and outfeed side of the machine. Gauge block for setting height of router arbors. -- Spindle Motors:18 x 3 kW (4 HP), 18,000 RPM, 230V, High Speed Spindle Motors. 100 HP VFD Inverter to drive and control rotational speed of all 18 spindle motors.Variable RPM of Spindle Motors through Potentiometer and RPM displayed on Control Panel. Individual Ammeter for each Spindle on Control Panel. 6 x banks with 3 x High Speed Spindle Motors per bank (18 Total Spindle Motors). All 6 Spindle Banks are adjustable on the Overhead Beams by Hand, and lock into Position via locking handles. Digital Read Out for horizontal position of each spindle bank. Spindle 1 on each bank is fixed horizontally, Spindles 2, and 3 adjust on each bank horizontally. All 3 spindles adjust individually vertically on each spindle bank via Hand wheel. Position of depth on Digital Read Out.All Spindle raised individually through pneumatic cylinder for changing tooling, or when not in use. Each Bank has a phenolic Hold Down Shoe.Spindle Centers adjust from 3" to 4" Centers; Rapid Center Adjust Switch, from 3" to 4" through Air Cylinders against positive s

STAR V MACHINERY SLW-6018 SLAT WALL GROOVING MACHINE: -- Specifications60" (5') Wide panel capacity, feed through style overhead milling Slatwall machine. The machine will produce 5' x 8' panels in portrait orientation or any orientation as long as the panel size does not exceed 5' x 5'.The panels are placed with side to be grooved, facing up, then pushed in between the fixed fence and a movable fence, until the panel is grabbed by the first rubberized feed roller, the panel is then transported between a number of pinch rollers and processed through 3 rows of high-speed spindle motors.As the T Slot cutting is processed each bank (6 in total) of 3 high speed spindle motors cut a T shaped groove appropriate to the size of tool installed in each spindle, blow the groove clean by use of high-speed air knives, and remove dust through a number of dust ports. Then pinch rollers push the sheet out of the machine roller bed.Panels as narrow as 6" wide can be fed through the machine although workpieces less than 3/8" thick must be 48" wide. Workpieces as short as 24" can also be fed through the machine safely.Minimum recommended workpiece width, 6": Maximum workpiece width, 48": Minimum recommended workpiece length, 24": Maximum workpiece length, UNLIMITED: Maximum workpiece height, 1.5". -- Features:5HP 1750RPM, 460V Feeder Drive Motor through 50:1 Gear Box. 5HP VFD Inverter to drive and control feed speed through machine, 0-50 linear feet per minute. Heavy Duty Welded Tubular Steel Frame Construction. Stainless Steel Roller Bed with Rollers 6" on Center. 10x Linatex Rubber coated Feed Pinch Rollers Driven by 5Hp Feed Motor and Drive. Fixed Guide Fence & Movable fence to aid feeding of sheets into machine. Safety Fence around both sides along the length of the machine, with 1 gate in each side, each with safety interlock. Safety photo eye in infeed and outfeed side of the machine. Gauge block for setting height of router arbors. -- Spindle Motors:18 x 3 kW (4 HP), 18,000 RPM, 230V, High Speed Spindle Motors. 100 HP VFD Inverter to drive and control rotational speed of all 18 spindle motors.Variable RPM of Spindle Motors through Potentiometer and RPM displayed on Control Panel. Individual Ammeter for each Spindle on Control Panel. 6x banks with 3x High Speed Spindle Motors per bank (18 Total Spindle Motors). All 6 Spindle Banks are adjustable on the Overhead Beams by Hand, and lock into Position via locking handles. Digital Read Out for horizontal position of each spindle bank. Spindle 1 on each bank is fixed horizontally, Spindles 2, and 3 adjust on each bank horizontally. All 3 spindles adjust individually vertically on each spindle bank via Hand wheel. Position of depth on Digital Read Out.All Spindle raised individually through pneumatic cylinder for changing tooling, or when not in use. Each Bank has a phenolic Hold Down Shoe.Spindle Centers adjust from 3" to 4" Centers; Rapid Center Adjust Switch, from 3" to 4" through Air Cylinders against positi

STAR V MACHINERY SLG-2000 36 LINEAR V-GROOVER: -- SpecificationsWorking table dimensions: 120" Long x 36" wide; working width: 6" - infinite" (152 mm - infinite); working length: 20" - infinite (508 mm - infinite); working thickness: 0.25" - 1.15" (6 - 29 mm).Max. throat clearance for linear & crosscuts: 14-1/2"/24-1/2" (355/622 mm). -- Equipped with: (2) Independent 10 HP - 3,600 RPM saw motors with: "Servo" control adjustment in "Y" axis & manual "Z" axis adjustment.30 mm Dia. arbor x 76 mm (3") clamping length to accommodate wider cove backsplash, triple fold profiles, or using it for hogging and finish cut; 9-1/4" (235 mm) max. cutte-rhead dia.(1) Saw motor mounted on the front & (1) Saw motor mounted on the back of the 8" x 12" x 1/2" heat treated steel Heavy-Duty overhead support beam.Side-to-side head travels via linear rails & bearings; manual head height adjustment via linear rails & bearings. -- Feeding System(1) 3 HP Variable speed drive belt system with: "Servo" height adjustment; feed rate: 0 - 45 FPM (12 MPM); belt feeder moves workpiece on a precision "aluminum" roller table. -- Tape Applicator (2) Automatic Tape Applicators with: "Servo" adjustment according to the Saw motor position in "Y" axis. -- Operator Interface10" HDMI Touchscreen display for: Start/Stop, On/Off, Feed Speed & Axis Position. -- Complete with:Safety guards and cutter guards; Anti-Kickback Device; Emergency Shutoff line.Dust Collection requirements: 4,200 CFM; Collector outlets on cutter guards: 5" in dia. -- Actual model #: STAR V MACHINERY SLG-2000

STATE B-4 OSCILLATING SPINDLE SANDER 1.5 HP Motor with manual switch, (9) spindles from 1/4" DIA to 4" DIA., 1,725 RPM spindle rotation, 20" x 24" table tilts 15° up and 45° down, table height 40". Also includes work light

STATE - B-4, ...Oscillating Spindle SanderSpecificationsTilting table design with pedestal floor mount.Table size: 20" x 24".Table height: 40".Table tilt: 15° Up; 45° down.Spindle speed: 1,725 RPM.Vertical oscillation: 1-5/8".Oscillations/Min: 90.Lubrication: Oil bath splash. -- Heavy-Duty 1/2 HP motor; maintenance free; 1,725 RPM; TENV totally enclosed non-vented motor; rated for continuous operation; assuring long term dependable service. -- Safe operator controls; magnetic motor starter with overload protection for save installation.All controls mounted for operator convenience. -- Operator friendly handwheel tilting Engineered worm gear design allows table to be tilted 15° up & 45° down relative to spindle.Easy-to-read scale allows for accurate tilt determination before engaging locking device. A tapered pin locks the table during horizontal sanding operations. -- Safety features: Magnetic motor starter with overload protection; safety labels; well-placed ergonomic controls; 3-throat rings to minimize table-to-spindle clearance; POSITIV-LOK spindles provide safe & quick means of changing spindles. -- Recently cleaned, checked; electrical contacts cleaned; machine partially disassembled cleaned; reassembled & tightened; oil sight glass replaced.Weight: 280 Lbs.

STATE D-30 DISC SANDERDynamically balanced 30" steel disc.Commercial duty direct drive 5 HP motor.Heavy cast iron 14" x 38" table w/miter gauge slot.Easy precise rack and pinion tilting of the work table with 45° down and 30° up.Motorized Rack and pinion adjustment of the table rise & fall. Sanding station is mounted to (2) 3-1/2" heavy columns.Heavy bolt-down cast iron base.

STEEL FAB 400 Gallon Vertical Air Receiving TankSpecifications: -- Tank size 36" Dia. x 6' H.

This listing Is for a complete line that consists of a Flow Coating line that feeds into a cross transfer oven and back out on to an outfeed conveyor making a 180 degree circuit. The heat exchanger needs to be heated by means of a hot water boiler or similar. Maximum Part width: 305 mmSpeed range: 2 - 10 m/min.Pos. 1 - FEEDING BELT CONVEYOR:For feeding the batches into the flowcoater, Belt with marked area to built a gap for the angle transfer, Technical Data: length: 2300 mmPos. 2 - IMPREGNATION MACHINE VEN FLOW:For flowcoating of profiles in continious production with a waterbased impregnation (viscosity similar to water)The material is is sprinkled on the surface and remains for appr. 10 seconds. After this time a high pressure air knife nozzles will blow the acess materialfrom the surface. The whole cabin is built with fall to the side to collect the rest of the material. It is reused after passing a filter system. The cabin is built of stainless steel. The blowing off of the access material by air knife is effected by a high pressure fan.The machine comprises:1 conveyor system with spray protected roller system length 3000 mm1 sprinkling zone with two nozzle systems adjusted to reach the whole surface of the workpiece. length: 200 mm1 penetration area length ca. 1000 mm time of residence ca. 10 sec1 blowing zone with adjustable knife nozzles air supply with high pressure fan air flow adjustable by frequency converter length ca. 1000 mmair speed ca. 40 m/sec. material supply to supply the two sprinklers with fluid and collector for recovered material.workpiece tolerances:twist: max. 1° on the whole length, straightness max. 0,5mm deviation/m in horizontal and vertical weight distribution: evenly on whole length coating material: waterbased impregnation. Unstable components can not be repositioned when tilted.Pos. 3 - MOULDING ANGLE TRANSFER VEN TRANS 90°conveying from lengthwise direction to crosswise, comprising:1 excenter-transfer arms integrated into the driven infeef roller conveyor. The tacted transfer system allows a minimum distance between the singlemouldings on the following cross transfer system.Technical Data:length of roller conveyor: 4500 mmroller pitch: 185 mmnumber of transfer arms: 22spacing 185 mmtacting cycle: max. 30/min.Pos. 4 - MOULDING CROSSWISE V-BELT CONVEYOR:Mouldings are conveyed by means of various v-belts along the system. The unit is fitted with an insulation cover between the conveyor. A drying tunnel is fitted on top of the unit.Technical data:length: 4000 mmoperating width: 4200 mmnumber of belts: 22distance of belts: 185 mmoutfeed prepared for an additional angletransfer:position of driving shaft in the middlegaps for passing of the carriers of the angle transferPos. 5 - JET DRYING TUNNEL 70 °C:Made of sandwich elements with fire preventing insulation material. The even distribution of air over the full operating width is reached by using slot nozzles on the full width of the tunnel. One combined heating-, fan

VESTIL EHLT-2464-2-55 Scissor Lift Full featured electric hydraulic scissor lift tables are used by all types of manufacturing and warehouse facilities.Safety features: -- Electric toe guard to protect pinch points during lowering of the table. -- Internal safety velocity fuse to maintain platform height in event of hose or fitting failure. -- Maintenance prop, and upper travel limit switch to stop table at maximum height. Specifications: -- 2,000 Lbs. lifting capacity. -- 2 HP totally enclosed electric motor. -- Platform size 24" x 64". -- Lowered height 7", raised height 55". -- 24V AC push button hand control. -- Hydraulic component rating of 3,000 PSI.

VESTIL EHLT-4896-4-56 Scissor Lift Full featured electric hydraulic scissor lift tables are used by all types of manufacturing and warehouse facilities.Safety features: -- Electric toe guard to protect pinch points during lowering of the table. -- Internal safety velocity fuse to maintain platform height in event of hose or fitting failure. -- Maintenance prop, and upper travel limit switch to stop table at maximum height. Specifications: -- 4,000 Lbs. lifting capacity. -- 2 HP totally enclosed electric motor. -- Platform size 48" x 96". -- Lowered height 8", raised height 56". -- 24V AC push button hand control. -- Hydraulic component rating of 3,000 PSI.

VIET - S211 R+ KRT, 2-Head Wide Belt Sander43" Width. cap.: Drum and Combination head.Head Configuration:1st Head: 160 mm 6.3″ Helical grooved rubber drum. 25 HP motor2nd Head: 160 mm (6.3") Helical grooved rubber drum with a platen combination head., 25 HP motorSpecifications: -- Each heads are powered by a 25 HP motor. -- The heads can be programmed to pneumatically raise & lower along with the platen and do (3) sanding combinations (with the twist of a button). -- Digital height readout and a calibration unit to the left side of the conveyor. -- Conveyor speed is controlled via a variable frequency drive 2.5 HP . -- Max width: 43″. -- Max. height: 6-1/4". -- Variable speed conveyor belt drive from: 3 - 16 MPM (11 - 52 FPM).Equipped with & Features: -- Both heads are equipped with: 1,130 x 1900 mm (44-1/2" x 75"). -- Roller & pressure shoe holddowns. -- Pneumatic tension of sanding belts and feed conveyor. -- Load meter on main motor. -- Disc brake on main motor. -- Emergency stops front & back. -- Roller table extensions front & back.NOTE: This is an extremely low-hour 2012 BIESSE Viet S1 dual head 43″ calibrating Wide Belt Sander.

Viet Opera 5-4.3 RRRR, (4) Head Wide Belt SanderCalibrating Sander (89 Hours)53″ wide cap. - Drum, Drum, Drum, DrumHead Configuration1st Head: 9″ Helical grooved steel drum powered by a 22 kW or 29.5 HP motor.2nd Head: VARIABLE SPEED (via VFD) 9″ helical grooved rubber drum powered by a 18.5 kW or 25 HP motor. 3rd Head: VARIABLE SPEED (via VFD) 11″ helical grooved rubber drum powered by a 15 kW or 20 HP motor. 4th Head: VARIABLE SPEED (via VFD) 11″ helical grooved rubber drum powered by a 15 kW or 20 HP motor.5th Station: Dust brush powered by a 1.27 kW or 1.7 HP motorSpecifications -- The durometer does get softer from head 2 to 3 and then from head 3 to 4. -- It has 53″ width capacity and a 200 mm or 7.87″ thickness capacity. -- Right above the machine's infeed, you will find inspection LED lighting, a digital thickness calibration unit, and a wireless Mitutoyo Digimatic Caliper that communicates with the Opera’s operating system. -- The vacuum bed is powered by an 11 kW or 15 HP blower under the sander to save space. -- The feed mat is powered by a 5.5 kW or 7.5 HP motor with variable speed via a VFD with feed speeds from 9.8 to 52.4 FPM.Equipped with & Features -- Inside you will find interior LED lighting while all the controls on this Opera are upfront via a touch screen -- Constant pass lineNOTE : This calibrating sander has a total of 1,982 power on hours and ONLY 89 run (conveyor) hours. This is a very loaded, LOW Viet Viet Opera 5 (4) Head 53″ Calibrating Sander

Biesse Viet Opera5 RRRF Widebelt Sander (4 head) 53" width capHead Configuration1st Head - Drum Unit -The roller working unit is characterized for the precision andeffectiveness of the work it does.Main motor 22 kW (30HP)Drum - 240mm - SteelLinear blower cleaning sanding paper A.S.S. (Air Saving System)Infeed pressure shoeThe pressure beam is used to guarantee the maximumprecision when calibrating and flattens the deformed or thinpieces. The chromed anti-wear metal removable tipsOutfeed pressure shoe2nd Head - Drum UnitMain motor 18,5 kW (25HP)Drum - 300mm - 70 ShoreLinear blower cleaning sanding paper A.S.S. (Air Saving System)Infeed pressure shoeOutfeed pressure shoe3rd Head- Drum UnitMain motor 15 kW (20HP)Drum 300mm-40 shore4th Head- Superfinishing unitThe super-finishing pad is the evolution of the pad unit (Vietpatent, 1978). The pad unit has a "chevron belt" runningbetween the pad itself and the abrasive belt that guaranteestop-quality finishing and a longer performance to theabrasive.Main motor inverter 15 kW (20HP)Pneumatic “air cushion"; pad This pneumatic pad is the ideal tool to solve finishingproblemsContact insert for pneumatic pad made of steel + felt + graphiteLinear blower cleaning sanding paper A.S.S. (Air Saving System)Infeed pressure shoeSpecifications -- Working Width: 1350 mm (53.15") -- Constant Pass (Fixed Table) - Heads adjust up/down by program) -- Working Height: 200 mm (7.87")Equipped with and Features -- Laser Electronic Positioning for working thickness -- Motors with amp meters -- IPC Compact 15" Color Touch Screen Controller -- Vacuum Table with 7.5 HP Motor, -- Electronic System, IPC Control with feed speed up to 75 FPM. -- 50 Shore Rubber Conveyor -- Vacuum bed for short parts -- Front & Rear Extension Rollers (2 EACH)

BIESSE-VIET OPERA 5-3.3 Denibbing Sander with 53" Width Capacity:53" Width cap. Denibbing Sander with a patented combination of rollers and rotating/oscillating discs make the VIET Opera Sanding Machine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet goods, shutters, face frames, furniture, and much more. Ideal solution for all sanding applications including whitewood, stain, and sealer coats. Sanding Drums - Made of steel, mounted on eccentric Shaft, to adjust the sanding belt thickness - Drum rubber with helicoidally grooves, balanced and rectified - Dust collection hoods with special design for best performance - Pneumatic ON/OFF of unit from panel control - Sanding belt tension rollers made of steel, balanced and rectified - Front pressure rubberized roller (1 roller) - Back pressure rubberized roller (1 roller)Head Configuration: -- 1st Unit: (15) Rotating discs with Slide-out system for easy setup. 11 kW (15 HP) Electronic Inverter with inverter speed control. -- 2nd & 3rd Units: 300 mm dia. Teflon hub for 36 strips. Oscillating System with electronic 4 kW (5.5 HP) inverter speed controlled. Specifications: -- Working Width: 1,350 mm (53.15"). -- Constant Pass Line TM (Fixed Table). -- Working Height Opening: 200 mm (7.87"). -- Laser Electronic Positioning for working thickness. -- Min. processing thickness 3 mm, Max. processing thickness 200 mm. -- (2) Longitudinal rotating brush-backed sanding rollers. -- 5" Rotating sanding discs. -- Forward speed 3-16 m/Min. -- Vacuum Table with 7.5 kW (10 HP) Motor, Electronic System, IPC Control. -- 60-Shore Rubber Conveyor belt with ground laminair surface. Pneumatic belt tracking -- Front & Rear Extension tables with rollers. -- Emergency stop.Equipped with: -- IPC Touch-screen control: Simple & user-friendly "TOUCH SCREEN" IPC control with a color monitor. This control system supports the management of all machine parameters. -- PC processor provides control and feedback information to the machine in real-time. -- The software version can be configured for right and left-handed operation. -- Text-free user interface; icons facilitate the operator's task. -- Optional rotating blower attachment at the back to blow off dust particles as items come off the machine. Electric Cabinet: -- "Check panel" alarms with LED - Automatic Star/Delta starter for main motors - Pad-lockable main switch - Thermal relay protections on all motors - Amperometer for all main motors - Electronic digital readout with automatic thickness positioning - Motor protection IP 54Actual model is OPERA 5-3.3 XLL. Year on nameplate is 2020 but not connected until 2021. Weight is 4600 KG (10,200 Lbs).This machine works great and has been very lightly used in a small shop that found with the small volume of work this machine was Too High in capacity so better off hand sanding.

VIET (BIESSE) OPERA 5-3.3 XLL Denibbing Sander with 53" Width Capacity:53" Width cap. Denibbing Sander with a patented combination of rollers and rotating/oscillating discs make the VIET Opera Sanding Machine the ideal finishing solution for entry doors, cabinet doors, drawer fronts, sheet goods, shutters, face frames, furniture, and much more. Ideal solution for all sanding applications including whitewood, stain, and sealer coats. Head Configuration: -- 1st Unit: (11) Rotating discs with Slide out system for easy setup. 15 HP Electronic Inverter. -- 2nd & 3rd Units: 300 mm dia. Roller Brushes (Hub for 36 strips). Oscillating System with electronic 7.5 HP inverter. Specifications: -- Working Width: 1,350 mm (53.15"). -- Constant Pass Line TM (Fixed Table). -- Working Height Opening: 200 mm (7.87"). -- Laser Electronic Positioning for working thickness. -- Min. processing thickness 3 mm, Max. processing thickness 200 mm. -- (2) Longitudinal rotating brush-backed sanding rollers. -- 5" Rotating sanding discs. -- Forward speed 3-16 m/Min. -- Vacuum Table with 5.5 HP Motor, Electronic System, IPC Control. -- 50-Shore Rubber Conveyor. -- Front & Rear Extension Rollers. -- Emergency stop.Equipped with: -- IPC Touch-screen control: Simple & user-friendly "TOUCH SCREEN" IPC control with a color monitor. This control system supports the management of all machine parameters. -- PC processor provides control and feedback information to the machine in real time. -- The software version can be configured for right and left-handed operation. -- Text-free user interface; icons facilitate the operator's task. -- Optional rotating blower attachment at the back to blow off dust particles as items come off the machine. -- Includes matching transformer for 600 V to 460 V.

VITAP LINEA 42 Line Boring SystemSpecifications: -- (2) Drill heads of (21) spindles ea., drills from bottom up, ea. support with 2 HP motor and (21) spindle boring block w/panel support mounted on top; -- Drills panels from 100 - 3,000 mm in length, and 100 - 950 mm in width. Complete with: -- Digital readouts for boring blocks, 2,000 mm bar scale fence with (5) adjustable flip stops. -- (2) Moveable overhead pneumatic holddown cylinders, foot pedal for clamping & boring cycle.

VITAP ALFA - 27: Construction/Line Borer27-Spindle boring head on 32 mm centers; drills vertically from bottom-up and head rotates to horizontal position for edge boring; head rotation is pneumatic with switch control. -- 2-3/4" Max. drilling depth; 2-1/2 HP - 2,800 RPM motor; pneumatic drill head advance with speed control; head height adjustment with mechanical digital readout; 34" x 20" table size; max. workpiece width 31-1/2". -- Equipped with: Left- & right-side fences for construction boring; (2) pneumatic holddown clamps; 118" line boring fence w/flip stops; pneumatic foot pedal control; magnetic starter; overload protection.
