DURA-QUIP - VC-3532, ...Vibrating Conveyor: -- Specifications:35" Wide x 32' Long; Pan is 7" deep and has 1/4" round holes punched plate in most of length to allow sawdust to drop outside of Conveyor. -- Bottom frame is filled with concrete 12" deep and rests on coil springs to isolate vibration from the ground. Buyer to replace screens. -- Include: 10 HP TEFC 460 V Drive motor.

DUST TECHNOLOGY DT-50 Modular Dust Collector5 HP BALDOR Motor, compact 2-bag free-standing & self-contained Heavy Duty Dust Collector, rated @ 2,400 CFM, 9" - 11" static pressure at fan. -- Equipped with: 10" Inlet dia., (2) Cotton Filter bags with 66 sq. ft. filter area and (2) Plastic Collection Bags w/ 30 cu. ft. collection capacity. -- (2) Double "T" Bolt Straps and (2) Quick Release Metal Straps. Includes: Magnetic Starter

DUST TECHNOLOGY DT-150 Modular Dust Collector Free-standing self-contained internal air system, 15 HP Motor, rated for 6,000 CFM, 4-bag unit, 60 cu. ft. collection capacity. -- (4) Upper cloth filter bags with 133 sq. ft. filter area; 14" inlet dia., dust baffling system to fill bags evenly. -- Includes: 15 HP motor, magnetic starter, (4) Upper cloth filter bags with 133 sq. ft. filter area and (4) lower plastic disposable collection bags

DUST TECHNOLOGY DT-75 Dust Collector7.5 HP BALDOR Motor, compact 3-bag free standing & self-contained heavy-duty dust collector, rated @ 3,450 CFM, 9" - 11" static pressure at fan. -- Equipped with: 12" Inlet dia., (3) upper filter bags with 99 sq. ft. filter area (patented BEANE bags designed to be 99% efficient to .5 microns). -- Dynamically balanced sand cast poured aluminum high quality impeller with easy access; 45 Cu. ft. collection cap., dust is collected in 6-mil thick clear plastic or canvas collection bags for easy disposal or reuse, a unique adjustable baffling system assures even filling of bags. -- Includes: Manual motor starter with thermal overloads & push button station.

DUST TECHNOLOGY DT-100 Dust Collector3-Bag free-standing & self-contained heavy-duty dust collectorSpecifications: -- 10 HP BALDOR Motor, compact 3-bag free standing & self-contained heavy-duty dust collector, rated @ 4,450 CFM, 9" - 11" static pressure at fan. Equipped with: -- 12" Inlet dia., (3) cotton needle felt upper filter bags with 99 sq. ft. filter area or patented BEANE bags designed to be 99% efficient to 0.5 microns. -- Dynamically balanced sand-cast poured high-quality aluminum impeller with easy access; 45 Cu. ft. collection capacity. -- Dust is collected in 6-mil thick clear plastic or canvas collection bags for easy disposal or reuse, a unique adjustable baffling system assures even filling of bags. -- Includes Push-button Magnetic starter control.Dimensions: 24" Deep x 136" High x 107-1/2" Length; Weighs (810) Lbs.

DUST TECHNOLOGY DT-250 Modular Dust Collector Free-standing self-contained internal air system, 25 HP Motor;Specifications: -- Rated for 9,800 CFM, 5-bag unit, 75 cu. ft. collection capacity. -- (5) Upper cloth filter bags with 165 sq. ft. filter area; 16" inlet dia., dust baffling system to fill bags evenly. Supplied with & Includes: -- 25 HP motor with magnetic starter, -- (5) Upper cloth filter bags and (5) lower plastic collection bags. -- (5) Double "T: Bolt straps. -- (5) Quick release metal straps. -- Roll of 50 Lower Plastic Dust Collection Bags, 24" Dia. X 72" Long.Three Year Comprehensive Warranty

DUST TECHNOLOGY DT-200 Modular Dust Collector Free-standing self-contained internal air system.Specifications: -- 20 HP Motor, rated for 7,500 CFM, 4-bag unit, 60 cu. ft. collection capacity. -- (4) Upper cloth filter bags with 132 sq. ft. filter area; 14" inlet dia., dust baffling system to fill bags evenly. Features & Includes; -- 20 HP motor, magnetic starter; -- (4) Upper cloth filter bags and (4) lower plastic collection bags. -- (4) Double "T": Bolt straps. -- (4) Quick release metal straps. -- Magnetic starterThree Year Comprehensive Warranty

DUST TECHNOLOGY DT-200 Modular Dust Collector W/ Chip TransferFree-standing self-contained internal air system.Specifications: -- 20 HP Motor, rated for 7,500 CFM. -- (4) Upper cloth filter bags with 132 sq. ft. filter area; 14" inlet dia., dust baffling system to fill bags evenly. Includes; -- (2) Rotary Air Lock units with hoppers. 8" Bottom discharge openings. -- (1) Fan box (DT-FB-100) w/ 10 HP, 4,450 CFM blower unit w/ 12" main inlet diameter. -- (1) Master control panel. Made in the USA. Three Year Comprehensive Warranty

DUSTEK - M750: Interior Filter Bag Dust Collector7.5 HP Motor; compact 3-bag free-standing & self-contained Heavy-Duty Dust Collector. -- Rated @ 3,450 CFM; 9" - 11" static pressure at fan. -- Equipped with: 12" Inlet dia.; (3) upper filter bags with 99 sq/ft. filter area. -- Dynamically balanced aluminum impeller with: Easy access; 45 cu./ft. collection cap.; dust is collected in 6-mil thick clear plastic for easy disposal; a unique adjustable Baffling System assures even filling of bags.

DUSTEK M750 Interior Filter Bag Dust Collector7.5 HP Motor, compact 3-bag free standing & self-contained heavy-duty dust collector. -- Rated @ 3,450 CFM, 9" - 11" static pressure at fan. -- Equipped with: 12" Inlet dia., (3) upper filter bags with 99 sq. ft. filter area . -- Dynamically balanced aluminum impeller with easy access; 45 Cu. ft. collection cap., dust is collected in 6-mil thick clear plastic for easy disposal, a unique adjustable baffling system assures even filling of bags. -- Weighs (750) Lbs., 24" Deep x 136" High x 107-1/2" Length.

DUSTEK W-2500 Whispurr 5-Bag Dust Collector.Specification: 8,500 CFM; 25 HP ultra quiet, self-contained high efficiency internal return (5) bag dust collector; 16" Dia. inlet, dynamically balanced impeller. -- Unit includes: (5) 60" filter bags, straps, gaskets, magnetic bag holders. -- Includes: Magnetic starter.

DUSTEX W-2500 Whispurr 5-Bag Dust Collector. -- 8,500 CFM; 25 HP ultra quiet, self-contained high efficiency internal return (5) bag dust collector; 16" Dia. inlet, dynamically balanced impeller. -- Unit includes: (5) 60" filter bags, straps, gaskets, magnetic bag holders. -- Includes: Collection hopper w/ rotary air lock,

DUST-EX AG22 Abort Gate/Valve.... Automated two-way air stream diverter valve which prevents fires and explosions in dust collection systems and reduces the risk of fire in explosive prone work environments. A "safety measure essential" when clean air is returned to a building. -- Consists of: A lever arm that automatically directs a flapper damper in two different directions. -- Normal Position: The damper stays in a horizontal position (open) allowing the air stream to be directed/returned to the building -- Abort Mode: In the event of a spark originating upstream of an outside dust collector, a Spark Detection Sensor positioned in the air stream inside the building, sends a signal to de-energize an electro-magnetically controlled latch.The flap of the valve is very quickly switched to the abort/second position (closed) thereby diverting the explosion pressure/air stream to the atmosphere. Thus the inside work environment is protected from the explosion. -- Reset Mode: A pneumatically operated system is added to reset the damper position. -- Comes With: NEMA enclosure, 10" x 10" x 6". Enclosure for Pneumatics 22" x 22" -- All (3) flanged connections are 22" x 22'" square. -- Construction: Damper assembly is fully bolted to provide solid, reliable operation. -- The power adapter for the independent power supply is extra.Overall dimensions: 60" long x 36" wide x 43" high.Improve the safety of your work environment & help comply with NFPA codes!

DUST-EX HSAG-24 Packaged Safety Solution for a 22"x22" (24" dia. round equivalent) Return Air Rated for 10,000 CFM. System for mitigating fire and explosions in combustible dust environments, for the woodworking industries. Generally includes Abort Gate, Non -Return Valve and Spark Detection/Suppression Hardware and Controls as follows: -- 1.) VigiFlap Dust Sensor, Dirty Air 22": Sensor, dust level, adjustable capacitive for organic dust, requires intrinsic safety system (will not trigger combustion or ignition in gasses or fuels). -- 2.) VigiFlap Explosion Isolation Flap Valve (Non-Return) Valve, EV-VF22 (EPDM); 22" diameter, flanged inlet and outlet, locking mechanism; welded steel construction, safety red painted finish, domed flap (stainless steel), inspection/access door, EPDM gasket, grounding straps, inductive shutdown sensor, normally open or closed flap orientation, certified ATEX EN 16447, NFPA 69 compliant. -- 3,) Control Panel. One-Zone CP05 Control Panel 1 inlet, 1 outlet: UL698A Control Panel for use with NFPA 69 compliant Explosion Isolation Valves. Standard panel includes status lights, intrinsically safe circuit (1 Per Zone), monitored inputs (3 total), ability to add a secondary clean air isolation valve, output for system shut down and monitoring, drawings, installation instructions, NEMA 4 outdoor rated enclosure, UL and Canada UL listings. Allows for 120VAC or 24VDC input power. -- 4,) SPARK DETECTION & EXTINGUISHING, SINGLE ZONE, KIT for pipe sizes 20?- 40? diameters; includes Raptor Spark RS-CUSP1L Control Panel, (2) Spark Detectors, Extinguishing Kit, Flexible hoses, Audible Alarm & Warning Light. Single zone spark detection and extinguishing kit for duct sizes of ?20" - 39" diameter, RS-KIT02, includes Raptor Spark RS-CUSP1L control panel, (1) RS-PDK02 packaged detector kit with (2) spark detectors with mounting kits, (1) RS-PWE02 water extinguishing assembly with hose connections and spray nozzles, audible alarm, warning light, battery back up - ATEX certified, CE listed, FM approved. -- 5.) Packaged External Test Lamp Kit, RS-TLK02, duct sizes: 6" - 39" diameter, (2) RS-SD02 test lamps with (2) RS-MK02SD/TL mounting kits - IP 65 enclosure, ATEX certified, CE listed, FM approved. -- 6.) Optional Start up Service Assistance: a.) Start Up - Day Rate @ $1,750/day. b.) Travel Service: Day Rate @ $900/day. c.) Travel Expenses: Total $110/hr. - min. two hrs. required - total $220. c.) Start Up Service Hourly Rate is $160/hr. Min. (4) hrs. needed for a total $640. -- 7.) High Speed Abort Gate, EM-HSAG02-24, magnetic (24 VDC), 22" x 22" flanged inlet and outlet (24" round equivalent), control panel for, magnet power with status lights and manual test button, gate position verification monitoring, manual reset lever, weather hood with bird screen. Maximum volume and velocity: 10,000 CFM / 3000 FPM, clean air installations only, NFPA compliant when installed with listed spark detection system. -- 8.) Packaged dust probe

LHI 72" RFPR Wide Arbor Roll Feed Gang Panel Ripper with Custom 5' x 16' Automated Infeed -- Specifications: -- 30 HP Arbor Motor; 1/8" min. to 1-1/4" max. material thickness and 72" cutting width. -- 10" Dia. blade design cuts thru max. 2" thickness; -- 3-15/16" dia. arbor with 72" of usable width cutting capacity, min. panel length 30". -- 1-15/16" FAFNIR arbor bearings; with (8) steel feed rollers on 6" centers; fixed feed speed of 80 FPM -- 47-1/4" working height -- (1) Arbor Cart is included -- (2) 4" Dia. dust collection ports on top and (1) 8" dust collection port on bottom. Recommended 1,500 CFM Includes the Following Optional Items: -- 5-Strand powered Chain Deck; 12' long; arranged to feed 5' x 16' packages onto the Scissors Lift. Complete with controls for forward, reverse, and jog. -- 5-Sections of Gravity Rollers on Scissors Lift Deck -- 8,000 lbs. Infeed Tandem Scissors Lift with 5' x 17' Deck and 2-HP, 3-Phase Motor. Lift includes a backstop for initial alignment at the Rake Feeder -- (8) Polyurethane Rollers on 6" centers -- Variable Feed Speeds from 10 to 80 FPM. -- Rake Feeder for 16' long panels -- Auto-cycle for Rake Feeder. -- 6' Line Up Conveyor with Fence and Powered Pinch Roll Included Tooling: -- (36) Standard Saw Collars for Ripping -- (72) Standard 10" Sawblades for Ripping (Includes a spare set) -- (37) Standard Throat Plates for RippingQuick Setup Kit Included, Contains the Following -- Belt guide -- Belt Tensioner -- Hydraulic Arbor LockAdditional Arbor Setup Included. Contains the Following: -- Arbor Cart -- Cart -- Blade Box -- Arbor -- Bearings -- Sheave -- Throat Plate Rack -- (6) Throat Plates PRICE REFLECTS FACTORY'S 7% MATERIALS SURCHARGE ON $156,995, OR $10,990

LAUDERDALE-HAMILTON 62" RFPR MULTI-BLADE PANEL SAW: Specifications: -- (1) 50 HP main arbor motor for 0.125" min. - 1.25" max. material thickness; 10" Dia max. blade capacity with 1.25" minimum spacing between the blades. -- Minimum panel length of 30". 62" of usable width capacity. -- 3.9" Dia. arbor with 1.9" FAFNIR arbor bearings; positive powered steel contact feed rollers; fixed feed speed of 79 FPM. -- On average this machine cuts a bundle (42 sheets) of 3/4" Plywood. LVL, PB, MDF or OSB into narrow strips in 4 minutes or less.

LHI MBR-10 ROLL FEED GANG RIPSAW: Saw arbor with 25 HP arbor motor (30 HP and 40 HP available, see Options for pricing).Specifications: -- 1-15/16" Saw arbor bearings and 10" usable arbor. 12" useable arbor available. Uses 12" dia. x 1-3/4" bore saw blades. -- 1/8" to 2" Max. cutting depth on hardwoods and softwoods; 18" minimum stock length; 17" maximum stock width; removable and replaceable phenolic throat plates. -- Unique “swing down arbor frame"; for easy and fast blade changing. Blades are positioned using spacers.Feed system with: -- (2) 1 HP Feed motors with constant feed speed to be determined from thickness of wood, type of wood, and maximum number blades (average speed is set at 80 FPM). -- (6) Non-marking steel drive rollers; top and bottom rolls are powered for superior feeding capabilities; hand crank for easy feed roll height adjustment. -- Includes safe, fully enclosed belt and chain guards and double anti-kickback device. Features: -- Simple design, low cost, high performance. -- High production, fast setup, workhorse. -- Off-The-Shelf Parts are found locally for ease of maintenance.Options: -- 30 HP arbor motor & starter, add $1,150, -- 40 HP arbor motor and starter, add $2,300, -- Variable Speed Drive with speeds from 10 to 100 FPM, add $2,450. -- 12" Useable arbor space, add $2,950. -- 12" x 24T Blade,1.75" Bore, $115 each. -- 12" x 30T Blade,1.75" Bore, $165NOTE: PRICING DOES NOT REFLECT Mfg's 7% MATERIALS SURCHARGE

LHI RFPR ROLL FEED PANEL RIPPER - "BUILT TO ORDER SYSTEM" with the following equipment: -- Ripsaw: -- 72" Arbor - 50 HP arbore motor and 14 to 80 FPM Variable Speed Feed Rate (4-speed programmable via VFD) -- (8) Polyurethane Feed Rollers -- Arranged for 10" dia. blades to rip panel thickness from 1/8" to 1-1/2"; -- Single Point Thickness Adjustment -- Quick-Change Arbor Kit Additional Arbor Setup Including: -- (1) Arbor Cart, (1) Blade Box, (1) Arbor Shaft, (1 set) Bearings, (1) Arbor Sheave, and (1) Throat Plate Rack Automatic Infeed System: -- 4,500 Lbs. Capacity Hydraulic Scissors Lift with (4) loading ramps to feed and align 4’ x 8’ sheets into Panel Saw -- 110VAC/1PH Scissors Lift power unit -- Auto-Cycling Rake Feeder -- 6’ Line-Up Conveyor With Power Pinch WheelOutfeed Scissors Lift: -- 4,500 Lb. Capacity Hydraulic Scissors Lift with 4' x 8' top, (3) support ramps/cross-bars to allow fork access -- 110VAC / 1Phase power unit -- Auto Down Indexing -- Auxiliary Foot Pedal Control Blades, Collars and Throat Plates: 10" x 40T x 4 3/16 Bore, TGC, $105 eachBlade Collars: 3-15/16" ID x 4.18" bore x 1.25" wide, $135 eachAluminum Throat Plates, $35 each TERMS AND CONDITIONS: -- Delivery: 16-18 Week ESTIMATED delivery date assumes your order is received within one week of date of this quotation. -- A 5% Tooling & Steel Surcharge to be added to the machinery price when the total is known -- Installation technical assistance, $125/hr. plus travel time and expenses (if required) -- Customer responsible for own rigging -- Quote assumes customer will deliver material for testing (if required) -- Warranty: 1-year mechanical parts (electrical controls excluded) -- FOB: Shannon, MS 38868. ESTIMATED SHIPPING DATE: 16 TO 18-WEEKS --The delivery date is quoted as “estimated"; because the equipment manufactured is built to our customer's specifications. This estimate is made under the assumption that there will be no interruptions of labor, material shortages, or any environmental or other unforeseen circumstances. -- LHI is not responsible for any installation or production costs resulting from actual delivery dates which exceed the quoted estimated delivery dates. Accurate dates for the delivery will not be available until the equipment is in the manufacturing phase. If there are custom features for the quoted equipment then accurate delivery dates will be available when testing is complete. Please consult with the factory for updates to the expected delivery date.NOTE: PRICING DOES NOT REFLECT FACTORY'S 10% MATERIALS SURCHARGE

LHI MODEL RFPR ROLL FEED PANEL RIP SAWWith the following Standard and Optional Equipment: -- Roll Feed Panel Rip Saw - 72" Arbor - 50 HP motor -- 10 to 80 FPM (4-speed programmable or potentiometer) -- (8) Polyurethane feed rollers -- 10" Dia. blades (thickness-1/8" to 1-1/4") Infeed Scissors Lift 4,500 Lbs capacity -- 4' x 8' top -- (3) 2"; x 3"; support tubes for fork access -- 110 VAC / 1-Ph power unit -- Foot pedal control -- Automatic up-indexingOutfeed Scissors Lift 4,500 Lbs capacity -- 4' x 8' top -- (3) Support ramp/cross-bars to allow for access -- Auto down indexing -- 110 VAC / 1 Ph power unit -- Foot pedal controlSawblades: -- (10) 10" x 40T x 4-3/16 Bore, TGC Blades -- (10) Blade Collars, 3-15/16" ID x 4.18" bore x 1.25" wide Quick-change arbor setup with the second arbor: -- Arbor change cart (included with the arbor setup that comes with the saw to allow roll-out) Second Arbor Setup Includes: -- Cart -- Blade Box -- Arbor, Bearing -- Sheave -- Throat Plate Rack -- (6) Throat Plates Quick Change Kit: -- Belt Guide -- Belt Tensioner -- Hyd. Arbor Lock Quick Change Kit permits the operator to release the belt and unlock the arbor from the front side of the machine. Without the kit, the operator must open the rear guard to remove the belt and unlock the arbor -- (10) Blades for the second setup -- (10) Collars for the second setup 16-week ESTIMATED delivery: -- Delivery assumes order and down payment are received within (1) week of the date of quotation. Installation technical assistance for $115/Hr plus travel time and expenses Customer responsible for rigging Quote assumes customer will deliver material for testing (if required) Warranty: (1) Year mechanical parts (electrical controls excluded) This quotation is valid for 30 days. ESTIMATED DELIVERY DATE:The delivery date is quoted as 'estimated' because the equipment we manufacture is built to order and to our customer's specifications. This estimate is made under the assumption that there will be no interruptions of labor, material shortages, or any environmental or other unforeseen circumstances. LHI is not responsible for any installation or production costs resulting from actual delivery dates which exceed the quoted estimated delivery dates. Accurate dates for the delivery will not be available until the equipment is in the manufacturing phase. If there are custom features for the quoted equipment then accurate delivery dates will be available when testing is complete. Please consult with the factory for updates to the expected delivery date.NOTE: PRICING DOES NOT REFLECT FACTORY'S 7% MATERIALS SURCHARGE

LHI MODEL RFPR ROLL FEED PANEL RIP SAW WITH THE FOLLOWING STANDARD AND SPECIAL EQUIPMENT: Specifications: -- 72" Useable Arbor and 50 HP Arbor Motor -- 14 - 80 FPM Variable Speed Feed Rate (4-speed programmable or potentiometer) -- (8) Polyurethane feed rollers -- Arranged for 14" dia. blades and 4"; max cutting thickness -- Single Point Thickness Adjustment from 1/2" to 4" -- Arbor Quick-Change KitComplete with: -- Additional Arbor Setup, Includes: Cart, Blade Box, Arbor, Bearings, Sheave, Throat Plate Rack, and (6) Throat Plates -- (15) Blade Collars: 3-15/16" ID x 4.18" bore x 1.25" wide -- (15) 14" Carbide Tipped Blades: 40 Tooth with 4.188 bore -- Delivery ESTIMATED at (14) weeks; assumes order and down payment are received within (30) days of the date of this quotation. -- Technical Installation assistance - $125/Hr plus travel time and expenses -- Buyer is responsible for rigging -- Quote assumes customer will deliver material for testing (if required) -- Warranty: 1 Year mechanical parts (electrical controls excluded) -- This quotation is valid for 30 days.
