Woodworking Equipment For Sale

DOUCET - SRX-6: 6-Section Clamp CarrierSpecifications -- (6) Sections; 8-1/2' wide usable clamping width. -- (9) Clamps per section (approx. total of 54 clamps); with: Quick Attach System. -- 36" Opening clamps; 2-1/2" high x 4" jaw width.Complete with: -- Pneumatic panel flattener. -- 5 HP Hydraulic pump for rotation drive. -- Hydraulic clamp tightener.

DOUCET MFE 300 Lateral chain feeder for moulders and optimizers -- 3'0" x 16'-0" working deck for material length 2'0" - 16'0"; width 2" to 9.5" and thickness 1/2" to 4". -- Feed system: Hydraulic variable speed 50-300 FPM with a 20 HP power unit. In-feed (4) roller accelerator; (2) top steel rollers and (2) bottom drive roller. Additional idler rollers along feed fence to support lumber during feeding. -- Chains: Transport length of lateral chain feeder 3'0". (8) strands of C2060 chains on pneumatic up/down device to release lateral pressure on board when feeding. -- Pedestal: Feeder controls mounted to pedestal with extended cable. Interface relay to stop feeder when moulder is stopped. -- Adjustments: Tool less adjustment handles for quick setups. Easy access to for thickness adjustments at front side of feeder. -- AVAILABLE OPTIONSOne (1) set of four (4) feeding wheels made of steel with hardenedsurface teeth $ 1 000.One (1) set of four (4) feeding flat wheels made of steel, 2" wide insteadof 1" for wide material feeding $ 500.One (1) set of four (4) feeding flat wheels made of steel 1" wide $ N/C.Guiding Tunnel between feeder and moulder,Standard Guiding Tunnel (4' long) $ 1 650.Standard Short Guiding Tunnel (32" long) $ 2 100.Complete Guiding Tunnel (4' long) $ 2 700.Complete Guiding Tunnel with adjustable fence (4' long) $ 3 800.Motorized Guiding Tunnel (4' long) on request.Additional chain transfer length capacity (up to a maximum of 6additional feet) For MFE-300-16 sold per foot $ 1 685. Note: More than 6 add. feet: price upon requestSteel plates between chainsFor MFE-300-16 $ 1 050.Platen chains recommended for softwood speciesFor MFE-300-16 $ 2 850.One (1) additional chain for shorter material down to $ 1 750.18" min. lengthPressurized lateral guide with roller bearing end $ 1 400.Powered lateral guide with roller and side guides on request.Custom working height on request.

DOUCET X 60: Finger Jointer Line for Medium Production"X 60 DG" - Automatic feed Finger Jointer has Chain Feeding System: Driven on the bottom & right-and-left side; feeds board up to 6" max. width. Capacity -- 3/4" - 2" Max. thickness; 1-1/2" - 8" max. width with lugs on 11" centers; 5" min. - 48" max. material length. "X60 Right-Hand Shaper Sections; equipped with: -- 5 HP Trim Saw; 3 HP scoring; 15 HP Shaper motor. -- PLC Controls on Shaper section. -- Dual feed chain with: Lugs on 11" centers; 10 - 75 FPM variable feed speed; 5 HP feed drive. -- Max. width: 8"; Thickness from 3/4" to 3 1/2". -- PLC Controlled extrusion type Glue Applicator with: 12-Gal. tan; sound enclosure & cabinet type base. Transfer to the Assembly Press. Model "MP-32" Assembly Press -- 7' - 10' Max. in automatic mode & up to 20' in manual mode cutoff cap.; automatic cycling; 90 FPM powered infeed flat top chain with side alignment rolls to the pre-assembly tunnel. -- Pieces are fed through with bottom & side chain through the Cutoff Saw to a movable limit switch and cut to length; 5 HP upcutting Cutoff Saw for continuous assembly; 2" x 9" cap. with 14" blade; finished lengths are pushed out by the next piece onto material outfeed arms. -- PLC Controlled Press section;10 HP hydraulic unit; 10,000 Lbs max. pressure. -- Gluing system with pump.System Includes & Supplied with: -- Stainless friction plates on assembly table; board holddown on all (4) sides. -- Automatic ejection of finished board with table. -- 6-Bolt cutterheads for hardwood and softwood.Production Capacity: Approx. 8,000 linear ft./shift or more; based on 12" average infeed length.

DOUCET BT3-30-5-23-G-PT Return Conveyor for Edgebanders Specifications: Right-hand feed, with Left-hand return. Min. part size 4" x 12". Max. panel size (with operator assistance supporting then turning panels) 45" x 96". Equipped with: 1-1/2’ L Infeed roller conveyor section, with (5) 23-1/4” W & (2) 34-1/4” W Rollers. 34-1/4” W x 5-1/2’ L x 35” H Receiving table, with Automatic/Manual height adjustment 2". (8) 3/8” Dia. transfer belts, (3) on 3” Centers, (2) on 6” Centers, & (3) on 9” Centers. 29-1/2” W x 5-1/2’ L x 34” H Return table. 29-1/2” W x 18’ L x 34” H 3-Section Return conveyor, with 5-1/2” W x 6’ L Gravity roller conveyor side extension. All rollers 1-7/8” Dia. covered line shaft on 3” centers. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

Doucet Clamp Carrier Model SRH-40-8.5-240-36 40 Section Clamp 8.5' Wide (240) 2-1/2" x 36" Clamps - Rapid Change Voltage: 480/3/60

- 16.5' long - 16 rotating arms and a total of 288 - 32" clamps

DOUCET CLAMP CARRIER 30 SECT X 8 FT 6 IN WIDE (200+) 36" CLAMPS MODEL SRH-1 SX30- 8.5-240-36 SN 87-10-28 Includes: HYD PWR PACK, PANEL FLATTENER Dismantled and ready to load!

Good Condition 3 phase .5 HP motor

"NEW" Doucet RC - STOCK Gluer - Table top unit for glue applications on a smaller scale. Motorized stainless steel roller equipped with a 2 Litre capacity reservoir easily removable for clean up. -- Spread roller: Stainless steel with roller dimension 8" X 3 1/2"; speed of roller 50 FPM. -- Table top dimension: 20-1/2" x 13".

Doucet MSP-CR-19-48-15-TRF-C-8-7 Conveyor

DSI - LD-1: CNC Lockdowel PressSpecifications -- The DSI machine is designed to squeeze Lockdowel hardware into the edge of a predrilled panel. Lockdowel machines: (5+) Have years of actual factory usage and inserts (10s) of thousands of Lockdowels successfully, accurately, and quickly! Features. Heavy-Duty construction. No "compressed air requirements only." Single-phase 120 VAC. - A large powerful drive motor. Rack & Pinion: Movable fence, extruded aluminum beams, and cross members. Solid aluminum fences with full adjustment capability.Benefits. Low cost alternative to those which have horizontal drilling capabilities, and do not want to invest in substantially more expensive machines that both drill & insert.Immensely faster and much more accurate than hammering; Lockdowels in by hand - A (1) or (2) person operation.Up to (8) Lockdowels inserted per machine cycle. Safety: Compact, safe, and accurate. Machine functions are supervised by: Safety rated control system including: 2-handed cycle start operation required. Safety light curtains & conveniently located emergency stop buttons.Operator Interface. The DSI machine includes a large touchscreen for quick data entry and quick accuracy adjustments.Portable: The machine is on Heavy-Duty casters. The infeed table folds down and out of the way.

DSI LD-1 CNC LOCKDOWEL PRESS:Specifications -- The DSI machine is designed to squeeze Lockdowel hardware into the edge of a pre-drilled panel. Our machines have over 5 years of actual factory usage, inserting tens of thousands of Lockdowels successfully, accurately, and quickly!! Features: Heavy duty construction. No compressed air requirements-only single phase 120 VAC. A large powerful drive motor. Rack and pinion movable fence and extruded aluminum beams and cross members. A solid aluminum fences with full adjustment capability.Benefits: A low cost alternative to those which have horizontal drilling capabilities and do not want to invest in the substantially more expensive machines that both drill and insert.Immensely faster, and much more accurate than hammering the Lockdowels in by hand. One or two person operation.Up to 8 Lockdowels inserted per machine cycle. Safety: Compact, Safe, Accurate. Machine functions are supervised by a safety rated control system including: two handed cycle start operation required. Safety light curtains & conveniently located emergency stop buttonsOperator Interface: The DSI machine includes a large touch screen for quick data entry and quick accuracy adjustments.Portable: The machine is on heavy duty casters. The infeed table folds down out of the way.

Dubois Lineal Sprayer with Guns

Dubois Gas Fired Oven

DUBOIS Vertical Edge Fill System with Micro UV This machine is designed to fill voids and defects in edges for a smooth, quality finish. These coaters are ideal for filling porous open grain panels like oak, veneers, particleboard, and MDF. Compatible with solvent based, water based, and UV fill coating.1.1 One (1) Continuous chain transport system- Top and Bottom chain transport conveyor with speed matching attachment conveyor chain- Aluminum backed chain pads with EPDM covering1.2 Two (2) double sided vertical edge denibber/buffer- Operator side Adjustable up to 12"; wide, back side fixed edge- Post mounted vertical denibber head- 12"; dia. x silicon impregnated scuffing wheel, buffer wheel to be determined- Dust hood with 4"; connection- Vertical head oscillation for even brush wear- Inverter controlled drive provides speed control for brush and oscillation1.3 Two (2) double sided vertical edge fill stations- Operator side Adjustable up to 12"; wide, back side fixed edge- Electric motor driven Applicator and Doctor roll drives- Quick change applicator sleeve design, 1-1/2"; face- Stainless steel distribution pipe with spring tension- 9"; dia. chrome plated reverse roll- Stainless steel catch pan and drain lines- 3/8"; pail mounted pump and agitator- Spring loaded doctor bar, urethane dr. blade- Air cylinder dr. roll engagement with stroke adjuster- Inverter controlled drives provides speed control for applicator and doctorrolls1.4 Edge Cure UV Oven Banks- Each bank to consist of Two (2) double sided Fusion F600 Microwave UVovens- Space for two (2) future double sided Microwave UV Units- Individually adjustable three (3) position lamp power selector switch(300, 400 & 600 w/in.)- Irradiator cooling exhaust fan for each set of four (4)2. Control Panel System- NEMA 12 Hinged Door Enclosure, with disconnect, required fuses, door mounted buttons and cooling fans- Allen Bradley HMI, PLC items included- Top mounted panel cooling fan- Required Inverters· Edge Fill Finishing Machineo Top and Bottom Conveyor driveso Denibber/Buffer Brusheso Denibber/Buffer oscillatorso Applicator Rollso Doctor Rollso Reverse Rollso UV oven Exhaust fansDesign Parameters- Machine is located in Explosion Proof Area- Voltage= 480 V., 3 Ph., 60 Hz.- Design Speed = 70 - 200 FPM- Line height = 36";- Max./Min. Part Width: 12"; / 2";- Max./Min Part Length: 245"; / 24";- Max./Min Part Thickness: 1-1/4"; / 3/8";- Paint Color· Main Frame and Conveyor: Blue / TS White· Guards: safety yellowNotes:- ¼"; product has the potential of being processed in this machine but has less probably of being successful the wider the product.

Dubois 4 Head wire brush machine

DURAMAC - DUR52-2, ...2-Head Wide Belt Sander2-Head Wide Belt Sander with: Drum, combi-head, and brush cleaner. -- Max. working width: 52". -- Max. working thickness: 6". -- 23" Infeed load space. -- 50" Wide rubber conveyor belt size. -- 1st Head: Grooved rubber contact sanding drum; 40 HP, 230 Volt - 3-phase drive motor. -- 2nd Head: Combination contact drum & polishing platen; 30 HP, 230 Volt - 3-phase drive motor. -- Spring-loaded pinch rollers. -- Electronic belt tracking, pneumatic belt tensioning. -- (1) Rear top outfeed panel brush cleaning head, 0.5 HP, 230 Volt - 3-phase drive motor. -- Power raise & lower of worktable. -- Inverter driven feed works drive motor for variable speeds, 0 to 60 FPM. -- Front operator control station; motor ammeters. -- TOSHIBA Feedworks inverter. -- "DP-626S" electronic digital readout for setting table heightAlso Available: -- Transformer for 600 Volt operation, 112.5 KVA.

•Durand plywood stacker •Will stack panels up to 5ft wide x 10ft long panels •Serial # 1286 •Was in use on skinner/trimmer line when the plywood mill went out of business •Currently stored inside, and ready to load on a truck •No charge for loading

Line Shaft Ready Triple Combination Table Saw/Band Saw/Router all in one.

Maximum Assembled Product Size: 37.5” x 98” Minimum Assembled Product Size: 11.375” (vertical) x 9.75” (horizontal) with spacer blocks 7.5” (vertical) x 5.5” (horizontal) Maximum Framing Width: 4” Minimum Framing Width: 1.5” Tubular Steel Frame THK Linear Bearings and Rails (1) Allen Bradley Compact Logix PAC (4) Allen Bradley Kinetix Servos and Drives a. (1) Vertical Beam b. (1) Horizontal Beam (2) On the Upper Right Hand Clamp to ensure that uniform pressure can be applied regardless of the cut accuracy of the frame parts (1) Hoffman Upright Enclosure Allen Bradley Control Components (Push Buttons, Relays, Power Supplies, Buzzer, etc.) (1) Hoffman Air Conditioner for Electrical Enclosure EMS Press Control/Server Communication Software Package (4) Tregarne Woodwelder with Production Gun
