Woodworking Equipment For Sale

COMEVA NICRON ZENIT CNC Door Machining Center with ATC.Simple, robust, fast, and versatile CNC that can meet all your needs milling, drilling, trimming etc. passage and entry doors. Equipped with a Router milling motor, "Type D" drill head, and a Double End horizontal milling motor to work on edges of all types of doors.Machine Specifications. Head Composition: -- Milling Router with Tool Changer capability; Boring head with (6) independent vertical spindles, (3) in X-Axis and (3) Y-Axis; (2) horizontal double drill spindles in X-Axis: --(1) Double-End horizontal Router Head. The Double-End spindle has one of the outputs with a cutter for machining the hinges and the second output has cutter for milling of the lock and plate.Work Table: -- Rexilon Nesting type flat table slotted for vacuum distribution and with (12) pneumatic reference stops; -- Tool changer with six position tool rack on one side of table; -- (4) Independent vacuum zones; Working area is 2,600 x 1,300 x 200 mm (102" x 51" x 7.8").Control & Software: -- Mobile CNC control panel for all axes control c/w display, keyboard and mouse. -- Powerful OSAI controller for machining control on all axes, reference stops, vacuum zones, and working groups; -- CADCAM Software is UCAMAM V11 (standard version) with postprocessor (which translates to language of machine) drawings from images such as BMP, JPG, TIF, GIF, PNG, as well as vector files from any format Adobe Illustrator, DXF (AutoCAD), EPS, PLT, TXT. Draw with this software directly and has auto-nesting to optimize use of the material.Drives & Speeds: -- ATC Router is 9 kW, 18,000 RPM with DELTA Inverter. -- Horizontal double end unit is 2.2 KW, 12,000 RPM. -- X & Y-Axes Speeds are 10 m/Min (30 m/Min with safety barrier - faster speeds available); Z-Axis is 10 m/Min. Other Machine Composition. -- Piston Stops: (12) divided into (4) fields. -- Lineal Guides: H/Win 20 mm wide. -- Lubrication System: Central - manual. -- Vacuum Pump: 160 cbm/Hr. -- Standard machine voltage: 400 V, 50-60 Hz, 3-Ph. (Transformers available). -- Overall Dimensions & Weight: 3,300 x 2,150 x 2,100 mm (130" x 85" x 83"); Weight: 2,000 kG (4,400 Lbs).Optional: - Vacuum Cup Risers. - CE regulation (Light barrier and perimeter fencing ): ...$ 2,950.(included in price) -- Includes: Owner’s Manual with schematics; covered by a 1-Year Factory Warranty on parts (Electrical components normally carry 90 - six months warranty).Engineered & Manufactured by COMEVA S.L, in Spain.Stated machine price includes Software and Light Barrier and Safety Fencing.

COMEVA - NICRON 2C, ...CNC Door Machining Center with ATC and Flat Table for NestingSimple, robust, fast, and versatile CNC that can meet all your needs milling, drilling, trimming etc. passage and entry doors. Using available CAD software, it can also machine any designs such as raised panels on entry doors or special bevels on door jambs. - Equipped with a Flat Table compatible with nesting, Router milling motor, Double-End horizontal milling motor to work on edges of all types of doors is added to "free space" location. Also (see options below) for machining the hinges on door jambsMachine Specifications. Head Composition: -- Milling Router with Tool Changer capability, working in conjunction with the 6-position tool rack. This Router can machine the door knob/plate openings, rebate on edge of door frame. -- (1) Double-End horizontal Router Head: The Double-End spindle has one of the outputs with a cutter for machining the hinges and the second output has cutter for milling of the door latch opening.Worktable: -- REXILON Nesting type flat table slotted for vacuum distribution and with (12) pneumatic reference stops. -- Tool changer with 6-position tool rack on one side of table. -- (4) Independent vacuum zones; Working area is 2,600 x 1,300 x 200 mm (102" x 51" x 7.8"). -- Workholding can be achieved with zoned vacuum table (for milling on the top surface of doors and wider door jambs, raised vacuum cups for edge of doors and machining of hinges on door jambs (with optional jamb fixture device below).Control & Software: -- Mobile CNC control panel for all axes control c/w display, keyboard, and mouse. -- Powerful CNC Controller for machining control on all axes, reference stops, vacuum zones, and working groups; -- CADCAM Software is UCAMAM V11 (standard version) with: Postprocessor (which translates to language of machine) drawings from images such as BMP, JPG, TIF, GIF, PNG, as well as vector files from any format ADOBE Illustrator, DXF (CAD), EPS, PLT, TXT. Draw with this software directly and has auto-nesting to optimize use of the material.Drives & Speeds: -- ATC Router is 9 kW, 12,000 - 18,000 RPM with DELTA Inverter. -- Horizontal double-end unit is: 2.2 kW, 12,000 RPM. -- X & Y-Axe Speeds are: 10 MPM (30 MPM with safety barrier, faster speeds available); Z-Axis is 10 MPM. Other Machine Composition. -- Piston Stops: (12) Divided into (4) fields. -- Lineal Guides: H/Win 20 mm wide. -- Lubrication System: Central - manual. -- Vacuum Pump: 160 CBM/Hr, 7.5 HP. -- Standard machine voltage: 220 V, 50 - 60 Hz, 3-Ph (Transformers available). -- Overall Dimensions & Weight: 3,900 x 2,150 x 2,100 mm (154" x 85" x 83"); Weight: 2,300 kG (5,000 Lbs).Optional: - CE regulation (Light barrier and perimeter fencing ): ....................3,100 Euro- Raised (50 mm) Vacuum Cups. Recommend (8) @ 165 Euro......1

COMEVA - NICRON DOOR PRO, ...CNC Door/Jamb Machining Center with Automatic Tool ChangerGantry style flexible Door CNC Machining Center which can machine Hinges, Locks, Grooves, Door Face Patterns and many similar applications. The advantage of this machine over the NICRON DOOR C is this model can also resize the doors and its ability to machine the top/bottom of doors with the 90° rotation feature. It also has a floating head for grooving designs on the door faces while compensating for uneven door surfaces. Specifications: -- Max. working area - door length on X-Axis is 118.1" (3,000 mm). Max. X-axis speed of 230 FPM (70 MPM). -- Max. door width on Y-Axis is 51.18" (1,300 mm). Max. Y-axis speed of 230 FPM (70 MPM). -- Max. travel on Z-Axis is 7.87" (200 mm). Max Z-axis speed of 98 FPM (30 MPM).Working Heads: -- The machine is equipped with: (1) 9 kW Vertical router head with a 5-position Automatic Tool Changer (ATC); (1) 3.5 kW Horizontal head with double-end output spindles and 0° - 90° rotation; (1) 3.5 kW Horizontal motor for the lock milling, and a 0.37 kW floating head motor for grooving patterns on the door face. All drives are powered by Servo motors, X- & Y-Axis movement are via Rack & Pinion; Z-movement is with a recirculating ball-shaft.Working table: -- Table work area is 51.1" x 118.1" (1,300 x 3,000 mm). Table equipped with: (2) Adjustable width bars and (6) suction cups Load wheels, regulated by (5) reference pistons that rise & fall to secure the workpieces. The bars have integral suction cups powered by a VENTURI vacuum system. To work with doors, the machine is equipped with stops and gaskets for securing the door. Stops are mobile, and they can be used to hold doors and other parts.Operator Control Panel/CNC: -- Floor-standing operator panel is mounted on casters and houses the PC & OSAI CNC control hardware. PC motherboard is an ''INTEL Atom" 1.6 GHz CPU, modular system that offers a solution for the control of Servo drives and distributed input/output modules in a digital field bus and integrated II/O's. The dual-axes gantry has a Velocity-Feed-Forward function (VFF) that tries to look ahead with 256 precalculated blocks. It also incorporates a firmness control (Jerk) of the axes through advanced algorithms as well as tool store management & tool life. Advanced NC control powered by OSAI which is set up to control the Interpolated axes and all machine functions.COMEVA Software: Specially developed COMEVA DOORS software allows the machining of the main designs of hinges and slots you may find all over the market, including the machining on the upper side/edge of the door. Software carries a series of predesigned macros that help the operator when performing the different operations, thus speeding up various job designs. The software carries out a special program of parametric macros for doors/door frames.Includes: -- Centralized machine lubrication system. Owner’s Manual with schematics software on USB

COMEVA - G-300, ...4-Axes CNC Controlled Door Frame/Jamb Milling Machine: Designed for cutting and milling the stiles and rails (headers) of door frames/jambs using a saw blade which rotates from +/- 45° & 90° straight cuts (rabbet-step cuts) and a router head for the milling pockets of all types of hinges and locks. --Specifications: Max. frame length of 118.1" (3,000 mm); max. frame thickness of 1.18" (30 mm); max. frame width of 9.84" (250 mm). Saw cut positions at +45°, 90°, -45°. Saw blade diameter of 11.81" - 12.28" (300 - 314 mm).Milling Group: Cutting and milling with (4) axes, X, Y, Z, & A , each with Servo motors controlled by CNC. Components from reputable manufacturers for guaranteed reliability, performance and quality. 1.5 kW - 18,000 RPM Router motor and 4kW - 5,640 RPM saw motor. X-Axis reaches a speed up to 290 FPM (90 MPM)COMEVA Software: -- Specially developed COMEVA DOORS software allows the machining of the main designs of hinges and slots you may find all over the market, including the machining on the upper side/edge of the door. Software carries a series of predesigned macros that help the operator when performing the different operations, thus speeding up various job design. Software carries out a special program of parametric macros for doors/door frames. This software is normally installed in user's own PC.NC Control: NC Controls for X, Y, Z & A-axis for tool positioning & processing. Axis movement via hardened round ways & ground ball screws. Advanced NC control powered by OSAI which is set up to control the (4) Interpolated axes. Comes with a PC with 19" display.Rails//Workholding: (4) Sliding rail units with (4) pneumatic fixturing clamps (aluminum and plastic) that can be moved for all frame sizes. (2) Side pistons put both frame stiles and the head rail in the correct position before starting the cycle. -- Includes: Owner’s Manual with mechanical & electrical schematics and parts breakdown; covered by a 1-Year Factory Warranty on parts. -- Overall machine dimensions: 134" x 99" x 63" high (3,400 x 25 mm x 1,600 mm) -- Engineered & Manufactured by COMEVA S.L, in Spain.

COMIL - XPRESS: Case Clamp (Automatic Feed Through)Specifications -- Working width: 180 - 760 mm (7.09" - 29.92"). -- Working length: 250 - 2,500 mm (9.84" - 98.43"). -- Working height: 250 - 1,300 mm (9.84" - 51.18"). -- Working table height: 500 mm (19.69"). -- Conveyor speed: 35 MPM (114 FPM). -- Beam speed: 18 MPM (59 FPM); horizontal: 20 MPM (65 FPM); Vertical (Combined). -- Beam pressure: 1,800 kG Horizontal (3,968 Lbs); 2,000 kG vertical (4,409 Lbs).Equipped with: -- Motorized belt conveyor: 31"; W x 17’ L x 26-1/2"; H. -- (2) Vertical beams with: Ball screw drive; each with: (3) Pressure bars; 0.37 kW (1/2 HP) - 2,750 RPM motor; rack & pinion drive. -- Top beam with: 2.9 kW (4 HP) - 1,500 RPM AC Servo motor and rack & pinion drive. -- Length & height Sensors. -- BIESSE "NC 400" CNC Control with: 6" Color LCD display.Complete with: -- 3' x 12' Pressure-Sensitive Safety Mat.NOTE-1: Infeed & Outfeed Conveyors NOT included.NOTE-2: Machine is currently being fed by 600 V, and Seller states there is a built-in Multi-Tap Transformer converting to 400 V.

--high output machine-- COMIL XPRESS Case Clamp (Automatic Feed Through) Specifications: Working width 180 - 760 mm (7.09" - 29.92"). Working length 250 - 2,500 mm (9.84" - 98.43"). Working height 250 - 1,300 mm (9.84" - 51.18"). Working table height 500 mm (19.69"). Conveyor speed 35 MPM (114 FPM). Beam speed: 18 MPM (59 FPM) Horizontal, 20 MPM (65 FPM) Vertical (Combined). Beam pressure: 1,800 kg Horizontal (3,968 Lbs.), 2,000 kg Vertical (4,409 Lbs.). Equipped with: 31” W x 17’ L x 26-1/2” H Motorized belt conveyor. (2) Vertical beams, with Ball screw drive, Each with (3) Pressure bars, 0.37 kW (1/2 HP) - 2,750 RPM Motor, Rack & pinion drive. Top beam, with 2.9 kW (4 HP) - 1,500 RPM AC Servo motor and Rack & pinion drive. Length & Height Sensors. BIESSE "NC 400" CNC Control, with 6" Color LCD display. Complete with: 3' x 12' Pressure-Sensitive Safety Mat. NOTE 1: Infeed & Outfeed Conveyors Not included. NOTE 2: Machine is currently being fed by 600 V, and Seller states there is a built-in Multi-Tap Transformer converting to 400 V. CURRENCY NOTE: Negotiable Price is listed in U.S. Dollars.

COMIL CF-2000 CASE CLAMP (AUTO FEED THRU):Automatically self-adjusting Feed-Through Clamp with: Pneumatic clamping pressure & electronic self-setting of clamping units according to cabinet size; cycle of machine can be timed to interlink with Production line.Working Capacity: -- Carcass length: 11.8" - 98.4" (300 - 2,500 mm); carcass height: 11.8" - 48" (300 - 1,220 mm); carcass depth (width) 11.8" - 39.8" (300 - 1,000 mm). -- Infeed/ through-feed conveyor belt at 19.7" (500 mm) floor height & variable feed speed from 24 - 123 FPM (7 - 37 MPM).Equipped with: -- (3) Horizontal clamping units. -- (1) Top vertical clamping beam operated by (3) pneumatic (double-acting) cylinders.Operator & Machine Control: -- Built-in operating control console with controller; LED readouts for programming of cycle time & pressure control.

COMIL CF-2000 JUNIOR ... Automatic Feed Through Case Clamp; - 28" Feed Through CapacityAutomatically self-adjusting Feed Through Clamp with pneumatic clamping pressure & electronic self-setting of clamping units according to cabinet size; cycle of machine can be timed to interlink with production line.Specifications:In-feed & thru-feed conveyor belt (feed speed 24 - 123 FPM) at 19.7" floor height. Max. feed through opening 28", max. length 100", max. height 48".Clamping System:(3) Horizontal clamping units, (1) top vertical clamping beam operated by (3) pneumatic (double acting) cylinders.Controls:Built-in operating control console with controller with LED readouts, for programming of cycle time & pressure control.Comes With:20 ft Motorized out feed conveyor - original COMIL

CONCEPTION CRP-180 Short Block Feeder Infeed ConveyorSpecifications: -- About 4 m long X 1.2 m wide, 2-ply rubber belt, friction back with Photocell for automatic operation -- Short Block Feeder; Blocks to be 25mm longer than width -- 14' rotating carousel with adjustable speed via VFD with Motorized wheel to avoid blockage -- Exit opening adjustable to the block width -- 200 mm x 7m long belt conveyor to carry the blocks to index rolls; Servo indexer controlling the flow powered by an electric motor; Speed-up belt powered by an electric motor -- Wane System: Scanner to detect wane integrated in conveyor -- Display screen to show wane detected; Kicker to kick blocks that are not in good orientation -- Conveyor to return it into the spreader belt conveyor -- Automatic Operations

CONQUEST 2-46 DOUBLE ROW LINE BORER --2) Rows of (23) spindles, drilling depth up to 2-3/8", drills from bottom-up; -- Specifications: (2) 2 HP BALDOR motors, 3,450 RPM spindle speed. - Adjustable opening between heads from 5-1/2" - 27" w/mechanical digital readouts. -- Equipped with: (2) Pneumatic holddowns, 120" back fence with (3) large flip stops, (2) air index pins for sequence boring long side panels; table height 37-1/2". -- Complete with: 10 mm Collets, position indicator, air/electrical controls, and foot pedal for clamping & boring cycle. -- Includes: Full set of 5mm bits.

CONQUEST 1-23H CONSTRUCTION / LINE BORERUSA-Made 46-spindle Horizontal/Vertical Boring Machine.Specifications: -- (2) 2 HP BALDOR Motor to drive a helical gear head with spindles on 32 mm centers. One head with (23) Spindles in the vertical plane and One head with (23) spindles in the horizontal plane. -- Pneumatic head movement to reduce operator fatigue. -- 20-1/2" x 36" Cast iron front table.Complete with: -- 98" Back fence with repeat stops. -- (2) Pneumatically operated index pins & (2) pneumatically operated holddowns. -- Collets that accept 10 mm shank bits. -- Bit requirements of 10 mm shank. -- Foot pedal control....$150.00 crate charge.

CONQUEST 1-23H Horizontal 32 mm Boring Machine;Specifications: (1) 23-Spindle horizontal boring head, 2 HP "BALDOR" motor, helical gear driven spindles spaced on 32 mm centers, 3,450 RPM; cast table. -- Equipped with: Pneumatic head activation, side fences. -- Complete with: (2) Pneumatically activated holddowns and foot pedal. NOTE: This unit has 2 sets of arms. All the screws have been replaced for the drill bits. Ready to go to work!

In stock and ready to ship! Coral EuroDry Paint Booth - 3500-11771 CFM - 5'-16' Wide

CORDES STAIR-ROUTER MODEL "40" Automatic CNC Stair Stringer Router CORDES STAIR-ROUT "40" Fully Automatic 3-1/2 Axis CNC Stair Stringer Router for trenching box stairs, centers, 45° cut but not open stairs.. Unit automatically cuts rise, run, and advances to the next board. This model was developed over (4) Generations of improvements. Basic Operation: -- Operator inputs the parameters for rise, run and number of cuts & press start on the user friendly display, in decimal or fractions & no programming is needed. -- After cutting, an operator makes a choice of repeating with the same parameters (default) or entering changes to one or more parameters. Specifications -- Double or Single Stringer 6" - 14" by 5/4" to 2-1/2"; For clean cuts (2) high speed 5.5 HP high frequency motors with solid state variable speed drives; 1/2" dia. capacity tool shank. -- CNC control: Minimal operator training needed; Operator can choose to repeat a cycle or change parameters and automatic rise, run, cutting and board advance; Standard Box Step Route with Round Nose; Screen displays a diagram of step; heavy duty steel construction.Machine Selections can be divided into (3) groups: -- a.) Basic Operator: Includes Rise, Run, No. of Rise, Type of Rout, Thread Thickness, Nose Length, Stringer Width, Tool Dia., Tread Clean-out; -- b.) Advanced Operator: Nose Width, Nose to Fence, Pocket Length, Riser Thickness, Rise Wedge Angle, Run Wedge Angle, Tread Clearance, Riser Clearance, Top Riser; -- c.) Supervisor, in which a password is needed: Feeds, Speeds, Precision Adjustments, Component Operations, Password Changes, Statistics. Dimensions/Electrics: -- Footprint w/o overhang is 54" x 61", height 68" & weight is 3,500 Lbs; -- Electric load is 30A @ 208 - 220 V, 3 PH and 15A @ 115 V, 1 PH for control power; 80 PSI of clean dry compressed air.Features: -- The main actuators have both been rebuilt in the last couple of years by the manufacturer, CORDES". About $5k each.. Was running on 220 V single phase.

Cornell CLB Saw S/N CLBR-136

Cornell CLB Rip Saw S/N 17-12-93 W/Infeed

Cornell Single Arbor CLB Splitter.

Cosmic Fox 13 and Fox 16 CNC Router New machines

This Cosmec Conquest 250 CNC router with a 4x8 vacuum table is being listed for parts or as a restoration project. The CNC did run prior to being shipped to our shop a couple of years ago, but it has not been wired to power since then, and the working status is unknown. If you have a Cosmec CNC that needs parts replaced then this would be a great machine for you. Included in the listing are two Becker vacuum pumps (see photos for details) that could be can be hooked to this machine or plumbed to another.

COSMEC NR32-16CUK 510 CNC Router with ATC and Boring:63" x 122" Fixed table: Moving gantry design in a front-to-back configuration; 2-zone Phenolic vacuum table with pop-up pins for part location. -- Equipped with:(1) 10 HP "HSD" ISO 30 Type ATC spindle, 8-position side-mount tool carousel, variable spindle speed from 800 - 18,000 RPM, 11" Z-axis stroke. -- Boring unit:(1) 17-Spindle boring block (11) vertical and (6) horizontal and X-Axis - 5,000 RPM. -- Axis travel: X-Axis travel 3,190 mm (125.6"), Y-Axis travel 2,010 mm (79.1"), Z-Axis travel 280 mm (11.0"); Z-Axis clearance under rail 250 mm (9.84") - Rapid traverse on X- & Y-axis 38 m/Min (1,496 IPM). -- Control:OSAI series 10 numerical control with screen and including, 3-axis linear & circular interpolation, and RS 232 connection with a user-friendly operator interface. -- All axes Incorporate brushless, closed-loop Servo motors driving precision ball screws and ride on STAR linear guideways with an automatic lubrication system servicing the way and ball screw bearings. -- Complete with:Vacuum pump, assorted tool holders, and manuals.
