Sanders For Sale

MAKOR LTSI/6 Profile Sander(6) Stations, 6"Width Capacity (approx), PLC Controller. -- 5.5HP Variable Speed Feed Motor with (6) 6"W Powered Feed Belts. -- 1st Station: Tiltable Polishing Head 2HP MAKOR Motor with J1000 Drive. -- 2nd Station: Tiltable Polishing Head 2HP MAKOR Motor with J1000 Drive. -- 3rd Station: Tiltable Polishing Head 2HP MAKOR Motor with J1000 Drive. -- 4th Station: Tiltable Polishing Head with with 2HP MAKOR Motor with J1000 Drive. -- 5th Station: Tiltable Polishing Head with 2HP MAKOR Motor with J1000 Drive. -- 6th Station: Tiltable Polishing Head with 2HP MAKOR Motor with J1000 Drive.Dimensions are 20’ L x 5’ W, 8’ H, and weighs approximately 7,000 lbs.

MAKOR LTS/6E Profile Sander(6) Stations, 6"Width Capacity (approx), PLC Controller. -- 5.5HP Variable Speed Feed Motor with (6) 6"W Powered Feed Belts. -- 1st Station: Tiltable Polishing Head 2HP MAKOR Motor with Powered Cooling Fan and J1000 Drive. -- 2nd Station: Tiltable Polishing Head 2HP MAKOR Motor with Powered Cooling Fan and J1000 Drive. -- 3rd Station: Tiltable Polishing Head 2HP MAKOR Motor with Powered Cooling Fan and J1000 Drive. -- 4th Station: Tiltable Polishing Head with with 2HP MAKOR Motor with Powered Cooling Fan and J1000 Drive. -- 5th Station: Tiltable Polishing Head with 2HP MAKOR Motor with Powered Cooling Fan and J1000 Drive. -- 6th Station: Tiltable Polishing Head with 2HP MAKOR Motor with Powered Cooling Fan and J1000 Drive.

NASH - 50-72: Spindle Sander -- (10) Spindles; 72" chucking. -- Cap., 3/8" - 6" dia. range; 2-1/4" dia. main arbor with long keys for driving head & tailstock wheels. -- Variable spindle speeds: 700 - 3,000 RPM; 7.5 HP spindle motor. -- 2 HP Feed & oscillation sanding rack motor; 60" max. sanding cap. with: (5) Sanding racks, self-adjusting and oscillating. -- Variable oscillating speed: (60 - 120) Strokes/Min; oscillating stroke adjustable up to 2" in length.Equipped with: -- Overhead mounted dust hood., -- Push-button control panel; production rate of (10 - 30) pieces/Min.

NASH 50-72 Spindle Sander(10) Spindles, 72" chucking cap., 3/8" - 6" dia. range;Specifications: -- 2-1/4" Dia. main arbor with long keys for driving head & tailstock wheels. -- Variable spindle speeds from 700 - 3,000 RPM, 7.5 HP spindle motor, 2 HP feed & oscillation rack motor, variable oscillating speed (60 - 120) strokes/Min, oscillating stroke adjustable up to 2" in length. -- (5) 72" Sanding racks, self-adjusting & oscillating. -- Equipped with: Overhead mounted dust hood, push-button control panel; production rate of (10 - 30) pieces/Min. -- Includes: brushes and sandpaper

NORTHTECH NT-6108ES-6 Edge SanderSpecifications: Sanding Belt is powered by a 3 HP 230/460V motor. -- The platen measures 6-3/4″ X 39″ and has NEW graphite. Rubber covered direct drive pulley. -- Equipped with: (1) 7-3/4" x 37" Adjustable side table and (1) 11-1/2" x 19" Adjustable end table; both side & end tables have vertical table travel w/hand wheel adjustment. Complete with: -- Magnetic controls with overload protection & dust hood with 4" dia. outlet.

NORTHTECH - NT-KL-920-PRK- B & NT-KL-920 PRK-U, ...Top & Bottom 3-Head Planer Sander3-Head bottom with: Planer, drum and platen; 3-head top with: Planer, drum, and platen 920 mm (36") wide.Capacity: 36" x 5" thickness.SpecificationsBottom Machine Model: "NT-KL-920 PPR". -- Infeed driven Conveyor: 37" x 72" Long. -- 1st Head: Spiral cutterhead; (8) rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 175 mm (7") Dia. and 50 HP motor. Segmented chip breaker before the cutterhead. -- 2nd Head: Contact roller; (280 mm) 11" in dia.; 70 durometers, powered by a 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head: 3-1/4" Pneumatic Polishing Platen; engineered as a combination station, air-cushioned & adjustable in pressure to various grits and materials application. Powered by a 30 HP motor. -- Lifting & lowering conveyor bed; 1-1/2 HP motor (includes auto. thickness setup device). -- Variable speed: 7.5 HP; inverter duty motor integrated with an AC inverter (VFD); control providing variable feed rate from 15 - 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control for: Conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads.Top Machine Model: NT-KL-920 PRR-U -- 1st Head - Spiral Cutterhead: (8) Rows of 15 x 15 x 2.5 mm inserts carbide knives; (4) sides for rotation; low tool cost.Cutterhead: 7" (175 mm) Dia.; 50 HP motor.Segmented Chip Breaker: Before the cutterhead. -- 2nd Head - Contact Roller: 11" (280 mm) Dia.; 70 durometers; powered by 40 HP motor; running at 3,600 FPM belt speed.Sanding belt size: 85" x 37". -- 3rd Head - 3-1/4" Pneumatic Polishing Platen: Engineered as combination station; air-cushioned & adjustable in pressure to various grits and materials application; powered by 30 HP motor. -- Lifting & lowering Conveyor Bed: Motor 1.5 HP (includes auto. thickness setup device). -- Variable speed 7.5 HP inverter duty motor; integrated with AC inverter (VFD) control; variable feed rate: 15 to 70 FPM for heavy calibration; LED readout feed speed indicator. -- Microprocessor Control: For conveyor bed positioning to high precision via keypad entry. -- Automatic electronic preset panel thickness gauge/micrometer. -- Automatic Air Jet blast cleaning system on both sanding heads. -- Powered dropdown Conveyor between Bottom & Top machine.Features (includes both machines) -- Massive monoblock base: 3/4" Thick plate steel weldments. -- Large dia. roller hold-downs; ball bearing supported; 65 duro UV rubber are standard features. -- Automatic soft start of main motors (Y-Delta). -- Disc braking/emergency shut down protection for: Sanding belt breaking, non-tensioned sanding belt; and mistracking of sand belt. -- All motors & electrics are CE-approved. -- Electronic oscillating belt tracking system. -- Au

NORTHTECH - NT-920C-200: 2-Head Planer Sander Specifications -- 2-Head. 37" width cap.; 1-knife planer head followed by a wide belt sander head. -- 0" - 6" Motorized opening with: PLC control; keypad entry; LED readout for part thickness. -- 1st Head. 6" Dia. helical planer head with: (6) Rows of staggered carbide inserts; each insert has (4) usable sides; 30 HP motor. -- 2nd Head. Combination sanding head with: 4-5/8" Dia. rubber covered contact roll; 2-1/2" wide finishing platen; 20 HP motor. -- 37" x 75" Abrasive sanding belt; solid-state belt tracking. -- 3 HP Variable feed drive from 15 - 50 FPM; endless belt conveyor with automatic tracking.Complete with: -- Infeed over thickness bar. -- Emergency stops at infeed & outfeed. -- Air-operated disc brakes on sanding heads. -- Electrical interlocks on main access doors. -- Electrical controls with overload protection. -- Motor load meters. -- Panel cleaning brush.

//This machine is in an Auction on exfactoryauctions.com// //Link to machine: http://exf.ac/i5z NORTHTECH NT-EV-920RC DUAL HEAD WIDE BELT SANDER 2-Head wide belt sanding machine with 37" capacity. - Heads: 1st head: 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. 2nd head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. Two (2) infeed and outfeed spring loaded hold-down rollers; 2 HP variable speed feed drive. Sanding belt size: 37" X 85" and with electronic belt tracking. Motorized opening between the conveyor and sanding bed. Ammeters for measuring motor loads.

NORTHTECH NT-KL-43-RC Wide Belt Sander (2) Heads;43" width cap. Drum, Combination Head.Head Configuration:1st Head: Rubber-covered contact drum with 25 HP motor2nd Head: Combination head with a rubber-covered contact drum and 2-1/4" wide finishing platen, 20 HP motor.Specifications: -- Thickness opening with PLC control, (DP-525 controller) keypad entry automatically adjusts to any thickness with LED readout. -- 37" x 75" Abrasive belts, TRU-TRAK solid state abrasive belt tracking. -- Variable feed drive 13 - 49 FPM, 2 HP motor. -- Endless belt conveyor, infeed and outfeed rubber covered pinch rolls. -- Complete with: 0" - 6" Automatic part thickness set up.Equipped with & Features: -- Infeed and outfeed rubber covered spring loaded holddown rolls. -- Feed emergency stops at infeed. -- Disc brakes on sanding heads, electrical interlocks on main access doors, and motor load meters. -- Note: Year of manufacturing has to be verified.

NORTHTECH NT-EV-920RC Dual Head Wide Belt Sander2-Head Wide Belt Sanding Machine with 37" capacity. Specifications: -- First head 8-1/4" Dia. grooved rubber contact roll, with 20 HP motor. -- Second head: Combination finishing platen with grooved rubber roller and polishing pad, with 15 HP motor. -- Two (2) infeed and outfeed spring loaded holddown rollers; 2 HP variable speed feed drive. -- Sanding belt size: 37" X 85" and with electronic belt tracking. -- Motorized opening between conveyor bed and sanding heads. -- Ammeters for measuring motor loads. -- Includes spare abrasive belts.

OAKLEY H-5 Double Sided Edge Sander. -- General Specs: With 7.5 HP -1,800 RPM TEFC motor; (2) 8-1/2" x 57-1/2" Cast Iron platens; 8" x 164" abrasive belt, 4,680 FPM belt speed. -- Equipped with: One 11" x 62" Cast iron side table on one side and (1) 19" x 64" cast table on the other side, (1) cast iron radius tilting end table, end table tilts 0 ° - 45°; 6" vertical table travel w/hand wheel adjustment. -- Features: Rubber covered direct drive pulley and idler pulley,Complete with: Magnetic starter with overload protection, (8) dead head radius ends with graphite covering, and (1) steel covered spare head roll.

Oakley Edge Sander

OLIVER 6910 Oscillating Spindle SanderPedestal style Spindle Sander constructed for rugged use .Specifications: -- 2 HP Motor drives and is connected through a flexible coupling, and can be installed or removed without disturbing the drive mechanism. -- Spindle speed 1,725 RPM, Oscillation speed 75 Cy/Min with 1-1/2" stroke length. -- Spindle quill runs in precision ball bearings, oscillated by a heavy duty worm & gear mechanism running in a bath of oil. -- (10) Spindle sizes provided: 1/4 x 5", 3/8 x 6", 1/2 x 6", 5/8 x 6", 3/4 x 9", 1 x 9", 1 1/2 x 9", 2 x 9", 3 x 9" and 4 x 9"; 100 grit abrasive sanding sleeve with each spindle. -- Large 24" x 24" precision ground cast iron table mounted on large trunnions that can be tilted 45° down and 30° up by use of a convenient handwheel. -- Complete with: Pedestal style stand.

OLIVER 5385 Single Head Wide Belt SANDER (37") 1-Head and 37" belt width Combination Sanding Head with rubber covered contact roll and adjustable finishing platen, 1/8" - 5" Thickness capacity, 36" width capacity.Specifications: -- 20 HP Main drive motor. -- 1 HP Variable speed (15 to 45 FPM). -- 1/4 HP Power raising and lowering conveyor bed motor. -- 37" X 75"; Abrasive belts for longer life and less loading.Features; -- Central control panel features digital thickness set-up control for accurate stock height and removal. -- Four post lift design assures accurate consistent results. -- Oscillating belt is controlled by an air sensor to prevent sanding lines. -- Finishing Platen is fully adjustable and can be removed. -- Multiple dust ports for efficient dust management. -- Independent motors run the sanding belt, feed conveyor, and table elevation for maximum power to each operation.

Oliver model M-5360.002 25″ double head wide belt sander.Head configuration1st Head; Drum2nd head: Combination HeadSpecifications -- 25" Width capacity -- Belt length is 75″.Equipped with & Features -- Operators manual, -- Misc supplies, and several extra belts.

OLIVER 5390 Dual Head Wide Belt Sander1/8" to 6" Thickness capacity 36" Width capacity.Equipped with: -- 20 HP main drive motor, 2 HP variable conveyor feed 15 to 49 FPM.Head configuration: -- 1st Head: Contact drum -- 2nd Head: Roller and PlatenFeatures: -- Digital thickness controller w/ thousandth's jog feature. -- Omron electronic eye sanding belt tracking. -- Variable speed drive 15 to 49 FPM -- Power raising and lowering of the conveyor with digital thickness set-upSpecification: -- Max. width cap 36" -- Feed motor 2 HP -- Elevation motor 0.5 HP -- Max. thickness 6" -- Min. thickness 1/8" -- Contact drum 1st head 8" dia. -- Roller drum on 2nd head 4.75" dia. with 2" wide finishing Platen -- CFM requirements 3600 -- Feed speeds 15 - 49 FPM -- Belt size 37" x 60".

Powermatic DDS-225 Drum SanderSpecifications: -- 5 HP Main motor, durometer rubber-coated steel drums, independently adjustable rear drum for fine tuning. The Cast Iron table incorporates (4) jack screws with chain drive timing to keep it level. -- Features: Heavy-duty poly conveyor belt, 0.25 HP feed motor coupled to 2-speed forward/reverse gearbox for 8 or 10 SFPM, and dual dust collection ports with directional baffles.

POWERMATIC - WB-25, ...Wide Belt Sander1-Head; 25" width capacity; 1/8" to 6" thickness capacity.Combination sanding head with: 4" Dia. rubber-covered contact roll; 2" wide polishing platen; micro-adjust platen; steel abrasive belt tension roll; steel idler roll: 25" x 75" Abrasive belt capacity.Equipped with: -- 15 HP 3-Phase main motor; 1 HP variable feed motor, 15 - 49 FPM. -- 1/4 HP Table raising & lowering motor with: Auto adjust thickness assist; 1/8" to 6" opening with (4) screw jacks. -- Double infeed & outfeed rubber covered holddown rolls. -- Complete with: -- Digital readout; air eye belt sensing; limit switch overtravel protection; magnetic starter; overload protection; load meter; emergency brake.Includes: Owner's manual & parts list.

POWERMATIC - RB-37, ...Single Head Wide Belt Sander1-Head, 36" width cap., combination sanding head. -- Includes: 4" Dia. contact roll & 2" wide polishing platen, micro-adjust platen; 15 HP main motor. -- Abrasive belt size: 37" x 60"; with air tensioning, air jet abrasive belt tracking. -- 1 HP Feed drive; variable feed speed of 15 - 30 FPM conveyor speed. -- 0" - 5-1/4" Opening with: (4) Screw jacks; double infeed & outfeed rubber-covered hold-down rolls. -- Complete with: Magnetic starter; overload protection; load meter; emergency brake.

20" Dia. dynamically balanced aluminum disc, 3 HP - 1,740 RPM direct drive motor; 15" x 27-1/4" table w/miter gage slot, tilts 30° upward & lowers 45° downward, 90° positive table stop; rack mechanism for raising & lowering table by hand crank, heavy bolt-down steel base. Complete with reversing switch and miter gauge. Also available in Single-phase in 2 HP motor.
