TIMESAVERS - 2321-23-21, ...Planer Sander (2) Heads2-Head; 36" width cap.Specifications: -- 1st Head. 6" Dia. Helical head with: (6) Spirals of 4-sided carbide inserts; 25 HP motor. -- 2nd Head. Combination head with: 5-1/2" Dia. contact roll and 2-1/2" wide finishing platen; 20 HP motor; sanding head with 37" x 75" Abrasive belt with "POSI-TRAK" electronic tracking. -- Dial indicators for height adjustments. -- Conveyor belt feed with Variable feed speed 20 - 45 FPM; automatic conveyor belt tracking. -- Anti-kickback fingers on infeed; planer head with sectional infeed shoe and double hold-down rolls on outfeed; double infeed and outfeed rubber-covered hold-down rolls on the sanding head. -- Motorized part thickness adjustment: 0" - 5" With mechanical digital readout. -- Minimum part length: 15"; pass line height: 33"-38". Complete with: -- Controls mounted on belt loading side; air activated caliper disc brakes on all heads; load meters for each head; 14" infeed loading area. -- Dust extraction: 3,500 CFM; compressed air usage: 3 CFM @ 90 PSI. -- Total load amps at 230 Volts - 145 Amps.

TIMESAVERS - 352 HDA, ...Abrasive Planer/Sander2-Head, 51" width cap. Heavy Duty Sander. -- 1st Head: Smooth steel contact roll, 11-1/2" dia., 75 HP motor. -- 2nd Head: Spiral Grooved hard rubber contact roll (11-1/2" dia.) , 75 HP motor; 52" x 103" abrasive belts (6,300 & 4,300 SFPM) with POSI-TRAK electronic tracking. Equipped with: -- Heavy-Duty solid rubber (no vacuum holddown) feed belt for Heavy-Duty operation. -- Motorized part thickness adjustment, 0" - 6" opening. -- 38" - 32" Conveyor height passline with MITUTOYO LED readout, conveyor belt feed. -- 5 HP Variable feed speed from 20 - 60 FPM, smooth rubber conveyor belt. -- Infeed & outfeed spring loaded holddown shoes, infeed emergency stop bar, anti-kickback fingers on infeed. -- Disc brakes on sanding head motors, 18" infeed load area, and motor load meters on sanding heads.

TIMESAVERS 43- 3 OB Orbital Sander3-Head, 43" width cap. with (2) Orbital heads and (1) finishing brush. -- 1st & 2nd Orbital Heads: Each orbital head with (1) 10" wide platen for a total of (2) platens, each platen features a "dual action" head with a high-speed orbit and combined back-and-forth oscillation to remove abrasive belt cross-grain scratches. -- "Quick change" system for abrasive material, (2) 7.5 HP main orbit motors, and 1 HP oscillation motor. 3rd Head: Rotary abrasive brush with 2 HP motor, single side brush wear/height adjustment. -- Conveyor belt feed with Ruff-Tex conveyor belt, variable feed speed from 5 - 20 FPM, infeed & outfeed holddown pinch rollers on all heads. -- 0" - 6" Motorized part thickness opening, constant pass line-height of conveyor bed assembly, extended infeed load area, motor load meters on sanding heads. -- Includes a DOUCET Return Conveyor System -- New transformer for 230 or 460 Volt, specifically for this machine is available at an additional cost

TIMESAVERS BM24-2 Wood Brush Sander. One 24" sanding brush is followed by a second brush for finish or sealer sanding. -- Includes MASTER SAND (1) set of hubs and hard nylon brushes. -- Drives: 7.5 HP Variable Speed Drives on each head. 1 HP Variable Mechanical feed drive. Feed speed is adjustable from 10 - 40 FPM. -- Features: Spring-Loaded holddown rolls that can feed min. 12" long parts. Rough-top conveyor belt. (2) dust outlet connections at 4" dia. requiring about 450 CFM each.Other Specifications: -- Sanding wheel diameters: 11" rotating at 200 - 1,200 RPM. -- Feed/Passline height variable: 29 - 34.5" -- Maximum workpiece width: 24". -- Maximum workpiece height: 5.5". Minimum thickness: 0.200" -- Dust collection required: 900 CFM. -- Machine dimensions/Weight: 58" Long, 48" wide, 52" high. 925 Lbs. -- Electrical Load: 21 Amps @ 460/3/60.

TIMESAVERS 52-20 ORBITAL SANDER2-Head, 52" width cap. with (2) Orbital heads.Specifications: 1st & 2nd Orbital Heads: Each orbital head with (2) 5" wide platens, each platen features a "dual action" head with a high-speed orbit and combined back-and-forth oscillation to remove abrasive belt cross-grain scratches. -- 1st Head: 7.5 HP 230/460V 3PH motor -- 2nd Head: Oscillating platen 7.5HP, 330/460V, 3Ph"Quick change" system for abrasive material -- Conveyor belt feed with Ruff-Tex conveyor belt, variable hydraulic feed speed from 5 - 20 FPM, vacuum bed assembly, infeed & outfeed holddown pinch rollers on all heads. -- 0" - 6" Motorized part thickness opening with mechanical digital readout, constant pass line of conveyor feed bed assembly, motor load meters on sanding heads -- Push button controlsNOTE: Feed Motor and Feed Belt have been taken apart for shippingThe above specs are taken from literature and considered accurate. As always please take advantage of the inspection period to verify.

TIMESAVERS 2331-04-334 DUAL HEAD DENIBBING SANDER2-Head, 42" width capacity Sanding / Denibbing system. -- (2) 5" Wide platens featuring a "dual" action head with a high-speed orbital movement and combined back & forth oscillation to remove abrasive belt cross-grain scratches; platens designed with a quick change system for abrasive material. -- (1) Nylon abrasive impregnated (150 grit) Cleaning / De-Nibbing brush, 10" dia., drive unit for brush rotation, brush wear adjustment via jack screws. -- Vacuum holddown conveyor system with variable feed speed 5 - 15 FPM. -- Double infeed and outfeed holddown pinch rollers. -- Power raising and lowering of the conveyor bed with AUTO-SET feature, 0" to 6" part thickness capacity. (4) DUFF-NORTON acme screw jacks under conveyor bed, 36" infeed conveyor area.....below in the comments see what the current owner says:

TORIT-DONALDSON ADMC AD8 DRYFLO Cartridge Dust Collector. A Mist collector designed for long-lasting high collection efficiency capture of coolant and machining oil mists in metalworking applications. Even smaller amounts of dust can be filtered in the dirty air stream. -- DRYFLO is a proprietary cartridge which outperforms electrostatic precipitators and mist collectors utilizing standard HVAC envelope and cassette filters. Filter unit features a unique air-side filter retention system allowing for quick filter changes with minimal worker contact with collected oil. -- Also feature three-stage Filtration via a.) prefilter, b.) wrap allowing, c.) the filter cartridge to drain and coalesce smaller coolant mist droplets in to larger droplets. Plus optional fourth stage HEPA filters available for applications where smoke exists or additional efficiency of discharge air is required. -- Overall data: Capable of 17,600 CFM; (8) Filter Cartridges, 1,760 sq. ft. of filter area, -- Complete with: Ground mounted fan powered by a 40 HP motor, belt-driven. Fan includes a variable volume inlet. In prior application clean air was not retruned to building. -- Blower currently setup for approx. 15,000 CFM with 40 HP, Baldor Super-E, 324T frame, 1.780 RPM motor. -- Enclosure dimensions: 133" long, 68" deep, 160" high. Filter weight is 7,300 lbs.

TORIT - 460-IRD-20: Dust CollectorAn easy and economical solution for a wide range of wood dust collection applications. Downflow air pattern allows airflow & gravity to move filtered dust to collection receptacles for longer bag filter life and reduced pressure drop.Specifications -- 20 HP Direct drive; floor mounted blower. -- Fan inlet: 17". -- CFM: 7,000. -- Set of filter bags. -- Steel elbow from fan to collector. Motor Starter included.

WEEKE VENTURE 106M (BMG 111) CNC MACHINING CENTER (W/ATC/BORING): -- Specifications: Working Capacity: "X" Axis is 123.2" (3,130 mm); "Y" axis is 61.02" (1,554 mm); "Z" axis stroke is 7.2" (185 mm); max. material thickness 5.9" (150 mm). -- Positioning Speed: "X" & "Y" Axis travel speed of 262 FPM (80 MPM); "Z" axis travel speed of 66 FPM (20 MPM).The machine head travels on THK linear motion guides on all axes. -- Worktable:(6) Movable K-Table support rails with: Side mounted raise-and-lower panel feeding rails; (2) vacuum pods per rail.(6) Pneumatic backstops; (2) pneumatic side stops create (2) working zones.Laser Positing System setup assistance for precise rail & vacuum pod positioning. -- Boring Unit:3 HP (2.3 kW) Motor; variable speed from 1,500 - 7,500 RPM; (12) vertical "QUICK-CHANGE" drill spindles: (7) Spindles in "X" axis & (5) in "Y" axis.(6) Horizontal spindles with: (2 + 2) In "X" axis & (1 + 1) in "Y" axis. -- Machining: (1) 12 HP (9 kW) Air-Cooled electro-spindle router with: HSK F63 Adaptor with: Programmable 1,250 - 24,000 RPM; constant torque from 9,000 - 24,000 RPM; RH or LH rotation; powered by a frequency inverter.(1) 8-Position ATC magazine located at the RH side of the machine. -- Operator & Machine Control: WEEKE IPC "PC 85 Power Control" + Windows "XP" + WoodWOP 6.1 Operating System; INTEL Core2 Duo Processor; "BECKOFF" PLC for (3) axes with: Linear, circular, & helical interpolation.17" TFT Monitor with: 2D / 3D "REAL-TIME" graphics; industrial keyboard; mouse for data entry.(1) SATA Hard drive; 160 GB; central USB front side bus connection; Ethernet connection 10/100 Mbit; all mounted in separate free-standing Control Panel. -- Complete with:(1) 84 m³/Hr Vacuum Pump: 3-Zone safety mats (will stop machine if operator enters the active work area); safety fences; scrap conveyor; handheld pendant controller. -- Actual Model is: WEEKE VENTURE 106M / BMG 111.

WEEKE - BHX 050: CNC Machining Center (Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 meter² of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.:Max. workable part size for: "X" Axis: 98.4" (2,500 mm); "Y" axis: 33.4" (850 mm); max. part thickness: 2.4" (60 mm). -- Min. worktable part size for: "X" Axis: 7.8" (200 mm); "Y" axis: 2.7" (70 mm); min. part thickness of: 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed:The BHX 050 reaches movement speeds of: 164 FPM (50 MPM) in "X" & "Y" axis; 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit(1) 2.4 HP (1.8 kW); Variable speed from: 1,500 - 7,500 RPM motor; (8) independent spindles with: (4) Spindles in "X" axis & (4) spindles in "Y" axis. -- (6) Horizontal spindles with: (2 + 2) In "X" axis; (1 + 1) in "Y" axis. -- Boring block has "QUICK CHANGE" Spindle System. -- Operator InterfaceWEEKE "POWER CONTROL" + Windows + WoodWOP 5.0 + Operating System; "IntelCore 2 DUO" Processor. -- 17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 Serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection. -- Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:&#9679 (1) "X" Axis grooving saw with: 9,000 RPM Motor; max. saw blade dia. 100 mm. &#9679 (1) 7 HP (5 kW) Electrospindle router with: Hydraulic "QUICK CHANGE" tool system & "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. -- Actual Model is WEEKE BHX 050

WEEKE - BHX 055: CNC Boring Machine (P to P Vertical) -- SpecificationsFlexible "Vertical" Machining Center that uses less than 5 sq/m of valuable floor space in addition to an innovative panel handling system. -- Working Cap.:Max. workable part size for "X" axis is 120" (3,050 mm); "Y" axis 33.4" (850 mm), max. part thickness 2.4" (60 mm).Min. worktable part size for "X" axis is 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "BHX 055" can reach movement speeds of 164 FPM (50 MPM) in "X" & "Y" axis & 50 FPM (15 MPM) in "Z" axis with total safety - providing an unmatched working capacity. -- Boring Unit:(1) 3 HP (2.3 kW) Variable speed from 1,500 - 7,500 RPM motor; (13) independent spindles with: (8) Spindles in "X" axis & (5) spindles in "Y" axis.(4) Horizontal spindles with: (1 + 1) in "X" Axis & (1 + 1) in "Y" axis.Boring block with "Quick Change" vertical spindle system. -- Operator & Machine Control:WEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor: International keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive: modem, Ethernet connection.Real time multitask processing: Programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices. -- Options Include:(1) "X" Axis grooving saw, 9,000 RPM, max. saw blade dia. 100 mm.

WEEKE - BHX 050: CNC Machining Center (Vertical) -- Specifications Flexible "Vertical" Machining Center: Uses less than 5 sq/m of valuable floor space; includes an innovative Panel Handling System. -- Working CapacityMax. workable part size for: "X" Axis: 98.4" (2,500 mm); "Y" axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for: "X" Axis: 7.8" (200 mm); "Y" axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning Speed"BHX 050" Reaches movement speeds of: 164 FPM (50 MPM) in "X" & "Y" axes; 50 FPM (15 MPM) in "Z" axis with total safety; provides an unmatched working capacity. -- Boring Unit(1) 3 HP (2.3 kW) Variable speed from: 1,500 - 7,500 RPM Motor; (8) independent vertical spindles with: (4) Spindles in "X" axis; (4) spindles in "Y" axis.(3) Horizontal Spindles with: (1 + 1) in "X axis; (1) spindle in "Y" axis.Boring block has: QUICK-CHANGE Spindle system. -- Operator & Machine ControlWEEKE "POWER CONTROL" + Windows + WoodWOP 6.0 + Operating System; "IntelCore 2 DUO" Processor.17" TFT Monitor; international keyboard; soft touch keypad; industrial mouse; RS-232 serial ports; USB ports; (1) 1.44 MB floppy disk drive; (1) CD RW drive; modem; Ethernet connection.Real-time multitask processing; programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure; complete set of safety devices.Options include:&#9679 (1) "X" Axis grooving saw: 9,000 RPM; saw blade dia. 100 mm.&#9679 (1) 5 HP (3.6 kW) Electrospindle router with: Hydraulic "QUICK-CHANGE" tool system; "ETP 25" tool holders; variable speed from 6,000 - 18,000 RPM. &#9679 Voltage transformer: 600 Volts operation. -- Actual Model: WEEKE BHX 050.

WEEKE BHC 350 4/10 CNC MACHINING CENTER: Specifications: -- Working cap.:"X" axis: 3,750 mm (147.6"), "Y" axis: 1,250 mm (49.2"), 80 mm (3.1") max. material thickness. -- Positioning Speed: "X" axis is 196 FPM (60 MPM), "Y" axis 164 FPM (50 MPM) & "Z" axis 66 FPM (20 MPM). The heads travels on THK linear motion guides on all axes. -- Worktable: (6) Moveable support rails, raise-and-lower panel feeding rails, (3) matrix style vacuum pods per rail.(6) Pneumatic backstops, (6) Pneumatic front stops, (2) movable pneumatic side stops, and the dual central zero-stop creates (2) working zones. -- Boring Unit:(1) 3.5 HP, 1,500 - 7,000 RPM Motor; equipped with (24) independent vertical spindles with (16) spindles in "X" axis & (8) spindles in "Y" axis.(4) Horizontal spindles with (1+1) in the "X" axis & (1+1) in "Y" axis;(1) "X" axis grooving saw for max. 100 mm dia. blade, 2,000 - 7,000 RPM. -- Machining:(1) 8 HP HSK F63 Liquid cooled electro-spindle powered by KEB frequency inverter, programmable from 1,200 - 18,000 RPM (constant torque from 9,000 - 18,000 RPM), RH or LH rotation. -- Operator & Machine Control:IPC control with "WEEKE MCC" + Windows "XP" + WoodWOP 5.0 operating system; 15" high resolution color graphic monitor, standard keyboard & mouse for data entry, 1.44MB floppy disk drive, CD ROM drive.EtherNET interface for possible LAN connection to office PC, RS-232 serial interface for simple PC connection; all mounted in separate free-standing control cabinet.WoodWOP allows for the machine to be programmed off-line with the same intuitive icon driven software that the operator has on the machine controller."BECKHOFF" programmable logic control (PLC) operating system for (3) axes; linear, circular & helical interpolation. -- Complete with:(1) 100 m³/Hr Vacuum pump, man-height safety enclosure around rear & sides of machine, 2-zone safety mats (will stop machine if operator enters work area). Actual Model is WEEKE BHC 350 4/10 .

WEEKE BHC VENTURE 7L CNC MACHINING CENTER (W/ATC, "C" AXIS): Specifications: Working Capacity "X" Axis is 190.5" (4,850 mm), "Y" axis is 83.5" (2,120 mm), "Z" axis stroke is 14.9" (380 mm), max. material thickness 5.9" (150 mm).Positioning Speed: "X" Axis travel speed of 328 FPM (100 MPM), "Y" axis travel speed of 164 FPM (50 MPM), "Z" axis travel speed of 66 FPM (20 MPM); The machine head travels on THK linear motion guides on all axes.Worktable: (8) Movable K-Table support rails with (3) vacuum pods per rail; (8) pneumatic back-stops, (8) pneumatic front-stops, (2) pneumatic side fence stops, (2) working zones.Boring Unit: 3 HP (2.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (25) vertical drill spindles, (14) spindles in "X" axis, & (9) in "Y" axis, and (2) offset for large 35mm drills. (6) Horizontal spindles with variable speed from 1,500 - 7,500 RPM, (2 + 2) in "X" axis & (1 + 1) in "Y" axis, grooving saw with 125mm diam. saw blade (1) NC controlled 0° - 90° "X" / "Y" grooving saw, variable speed from 1,500 - 7,500 RPM, 125 mm dia. saw blade.Machining: (1) 16 HP (12 kW) Liquid cooled electro-spindle router with HSK F63 adaptor, programmable 1,200 - 24,000 RPM, constant torque from 9,000 - 24,000 RPM, RH or LH rotation; powered by a frequency inverter. (1) NC Controlled "C" axis for 360° horizontal processing; (1) 8-position ATC tool changer magazine.Operator & Machine control: WEEKE IPC "MMC" Control + Windows "XP" + WoodWOP operating system; "Beckoff" PLC for (3/4) axes linear, circular & helical interpolation. 15" TFT color monitor, industrial keyboard for data entry, CD ROM & 1.44 MB floppy drives, modem, USB slot, RS-232 serial interface for possible simple PC connection; 40.0 GB hard drive, 512 MB of RAM, all mounted in separate free-standing control panel.Complete with: (1) 100 m³/Hr Vacuum Pump, 2-zone safety mats (will stop the machine if the operator enters the work area), and hand-held pendant controller.Under power and available for inspection.

WEEKE VENTURE 08M CNC MACHINING CENTER (W/ATC, "C" AXIS); -- Specifications:Working Capacity "X" Axis is 127.9" (3,250 mm), "Y" axis is 49.2" (1,250 mm) for boring & 52.2" (1,325 mm) for routing, "Z" axis stroke is 7.2" (185 mm), max. material thickness 4.9" (125 mm). -- Positioning Speed: "X" & "Y" Axis 263 FPM (80 MPM, "Z" axis 66 FPM (20 MPM); The machine head travels on THK linear motion guides on all axes. -- Worktable:(6) Movable K-Table support rails w/side mounted raise-and-lower panel feeding rails, (2) vacuum pods per rail; (6) pneumatic backstops, (2) pneumatic side stops create (2) working zones.Setup assistance through the PC control display for precise rail & vacuum pod positioning. -- Boring Unit:3 HP (2.2 kW) Motor, variable speed from 1,500 - 7,500 RPM; (12) vertical "QUICK CHANGE" drill spindles, (8) spindles in "X" axis & (4) in "Y" axis.(6) Horizontal spindles with (2 + 2) in "X" axis & (1 + 1) in "Y" axis; -- Machining: (1) 12 HP (9 kW) Liquid cooled electro-spindle router with HSK F63 adaptor, w/programmable 1,250 - 24,000 RPM, constant torque from 9,000 - 24,000 RPM, RH or LH rotation; powered by a 11 KVA frequency inverter.(1) NC Controlled "C" axis for 360° horizontal processing; (18) Total ATC positions with (1) 8-position ATC tool changer plate mounted on the head for "on the fly" ATC & (1) 10-position ATC rack mounted at the RH side of the machine base. -- Operator & Machine control: WEEKE IPC "PC 85T Power Control" + Windows "XP" + WoodWOP 5.0 operating system; "Beckoff" PLC for (3) axes with linear, circular & helical interpolation.15" TFT Monitor with 2D / 3D "REAL TIME" graphics, industrial keyboard for data entry, CD R/W & 1.44 MB floppy drives, modem, USB slot, RS-232 serial interface for possible simple PC connection; all mounted in separate free-standing control panel. -- Complete with:(1) 100 m³/Hr Vacuum Pump, 2-zone safety mats (will stop machine if operator enters work area), safety fences, scrap conveyor, hand held pendant controller. -- Actual Model is WEEKE VENTURE 08 M BHC

WEEKE - BHX 055: CNC Machining Center (Vertical w/ATC) -- Specifications Flexible "Vertical" Machining Center: Uses less than 5 sq/m of valuable floor space in addition to an innovative Panel Handling System. -- Working Cap.Max. workable part size for X-axis: 120" (3,050 mm); Y-axis 33.4" (850 mm); max. part thickness 2.4" (60 mm).Min. worktable part size for X-axis is 7.8" (200 mm); Y-axis 2.7" (70 mm); min. part thickness of 0.47" (12 mm). - Automatic infeed & outfeed from the LH or RH side. -- Positioning SpeedThe "BHX 055" can reach movement speeds of: 164 FPM (50 MPM) in X- & Y-axis; 50 FPM (15 MPM) in Z-axis with total safety; providing an unmatched working capacity. -- Boring Unit: (1) 3 HP (2.3 kW) Variable speed from: 1,500 - 7,500 RPM motor; (13) independent spindles with: (8) Spindles in "X" axis & (5) spindles in "Y" axis.(6) Horizontal spindles with: (2 + 2) in X-Axis & (1 + 1) in Y-axis.Boring block with: "Quick Change" vertical spindle system. -- Operator InterfaceWEEKE "Power Control PC 85" + Windows + WoodWOP 6.0 Operating System; Intel Core "2 DUO" Processor.17" TFT Monitor; international keyboard, soft touch keypad & industrial mouse; RS-232 serial ports, USB ports; (1) 1.44 MB floppy disk drive, (1) CD RW drive, modem, Ethernet connection.Real time multitask processing: Programs can be transferred via diskette or downloading by wire is possible. -- Complete with:Pneumatic part clamping devices; sound enclosure, and complete set of safety devices. -- Options Include:(1) 10 HP (7.5 kW) Air-cooled electro-spindle router with: HSK F63 Adaptor; variable speed from 6,000 - 18,000 RPM.(1) 4-Position ATC tool rack mounted on the machine cabinet side.(1) "X" Axis grooving saw: 9,000 RPM, Max. saw blade dia. 100 mm.

WEIMA C 150 Briquette PressSpecifications & Features: -- Produces 2" (50 mm) dia. Briquettes; -- Hopper opening of 41" x 41" (1,040 x 1,040 mm); hopper volume 1.43 cu/yd (1.1 cbm). Equipped with: -- 9 HP Hydraulic motor; 0.75 HP auger motor; hydraulic oil volume of 26.4 gallons (100 liters). -- Vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material; extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio at 2,600 PSI; hourly output up to 80 - 120 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors").Features: -- Briquette length control, chrome plated clamp, oil level switch, control panel side-mounted to hopper, and overheating protection for hydraulic oil. Solid German engineering. - Freight, start-up, discharge pipes, etc. not included.

WEIMA TH 1500 M Briquette Press (Square Brick) -- Specifications: Produces 5.9" x 2.3" (150 x 60 mm) rectangular briquette; hopper opening of 55" x 55" (1,400 x 1,400 mm); hopper volume of 2.46 cu/yd (1.88 cbm). -- Equipped with: 40 HP Hydraulic motor; 2.6 HP auger motor; 3.0 HP agitator motor; hydraulic oil volume of 264 gallons (1,000 liters). -- Volume reduction from chip/dust to block up at a 10:1 ratio; hourly output up to 800 - 900 Lbs. -- Features: Conical shaped agitator with curved hopper corners, "Bridge Breaker" mounted on agitator; automatic "On/Off" integrated in feeding hopper; hydraulic oil cooling, overheating protection for hydraulic oil. -- Complete with: Touch-Screen control panel on swivel mount; discharge ramp for briquette extraction, chrome plated clamp, and an oil level switch. -- Solid German engineering.

WEIMA TH 814 Briquetter A volume reduction of 90% is possible through the briquetting of wood, paper, aluminum and biomass or synthetics, providing significant savings in labor, disposal and storage costs.Material is hand fed or by dust system into the hopper, where an agitator pulls it into the auger and pressing chamber. Specifications: -- Produces 80 mm (approx. 3.1") dia. compacted logs; approx. 2.4 cu. yd. (55.1 x 55.1 x 37") square vertical hopper, 18 HP motor. -- Hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Volume reduction from chip/dust to block up to 10:1 ratio; approx. hourly output between 300 - 400 Lbs/Hr.Features: -- Auto on/off integrated into feeding hopper; automatic briquette length adjustment; conical-shaped agitator; dust connection at pressing unit.Options: -- Hydraulic cooling for 24-hour operation, heating for cold weather start-ups; plastic tubing discharge into Gaylord or carousel bagging system. .

WEIMA TH 714 Briquette Press (Cylindrical). -- Produces 2-3/4" (70 mm) dia. x 4" (100 mm) long compacted logs. -- Specifications: Approx. 1.4 m³ vertical hopper, 18 HP (13.5 kW) motor; vertical hydraulic ram compacts the material in the extrusion chamber to produce uniform material, extrusion chamber is continually filled via rotary screw type auger. -- Approx. hourly output between 240 - 280 Lbs/Hr ("quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors"). -- Equipped with: Centralized control panel for easy operation, MITSUBISHI Logic control & solid German engineering. -- Complete with: Auto on/off switch, auto length adjustment, & oil level sensor. -- Optional:: Hydraulic oil heater, hydraulic oil cooler, transfer piping and customization to customer material handling.
